Electric Linear Actuator
PSL 202
General TECHNICAL DATA
Force
[kN]
2
(maximum)
Stroke
[mm]
50
(maximum)
Handwheel Turns
[ /10mm Stroke]
12
Enclosure
EN 60529
IP 65
Ambient Temperature
[°C]
-20 to +80 (S2) / -20 to +60 (S4)
Weight (excluding Aux.)
[kg]
4,5
Actuation speed and TECHNICAL DATA
Actuator Type:
PSL202
Actuation speed:
0,5 mm/s
[50Hz] /
0,6 mm/s
[60Hz]
Power Supply
[V]
230 VAC 1~
115 VAC 1~
24 VAC 1~
400 V 3~
24 VDC
Frequency
[Hz]
50
60
50
60
50
60
-
Rated Current
[A]
0,08
0,09
0,15
0,18
0,75
0,87
0,3
max. Power Consumption
[VA]
37
40
37
40
37
40
24
Duty Cycle
IEC 60034-1,8
S2 30min S4 80% ED - 1200c/h
ditto
Motor Protection
blockable
Multifuse
Actuator Type:
PSL202.1
Actuation speed:
0,25 mm/s
[50Hz] /
0,3 mm/s
[60Hz]
Power Supply
[V]
230 VAC 1~
115 VAC 1~
24 VAC 1~
400 V 3~
24 VDC
Frequency
[Hz]
50
60
50
60
50
60
Rated Current
[A]
0,04
0,045
0,08
0,09
0,38
0,43
max. Power Consumption
[VA]
28,2
29,4
28,2
29,4
28,2
29,4
Duty Cycle
IEC 60034-1,8
S2 30min S4 80% ED - 1200c/h
Motor Protection
blockable
Actuator Type:
PSL202.2
Actuation speed:
1,4 mm/s
[50Hz] /
1,7 mm/s
[60Hz]
1,0
mm/s
Power Supply
[V]
230 VAC 1~
115 VAC 1~
24 VAC 1~
400 V 3~
24 VDC
Frequency
[Hz]
50
60
50
60
50
60
50
60
-
Rated Current
[A]
0,11
0,09
0,22
0,18
1,05
0,88
0,06
0,05
1,0
max. Power Consumption
[VA]
44
40
44
40
44
40
62
54
41
Duty Cycle
IEC 60034-1,8
Motor Protection
Thermal Switch
Multifuse
ACCESSORIES / Options
for power supply:
230 VAC 1~
115 VAC 1~
24 VAC 1~
400 V 3~
24 VDC
2WE
2WE Gold
Single / Double Potentiometer
PD
Positioner
PSAP
Position Transmitter
PSPT
Heating Resistor
H
Local Control
PSC
Enclosure
EN60529
IP 67
Legend:
= Motor current at rated torque, without accessories
= requires reversing starter contactor
= Maximum power consumption including accessories
= available
= at 25°C ambient temperature
= not available
Additional switches Standard
for 100 mA to 5 A
at 24 V to 230 V AC/DC
Additional switches Gold
for 0,1 mA to 100 mA
at 1 V to 24 V AC/DC
S2 30min S4 50% ED - 1200c/h
PS Automation GmbH
DB_PSL202_0608_E
Page 1 of 2
DIMENSIONS [mm]
PSL 202
Mounting Position
Dimensions for PS - Standard coupling
(For threaded valve stem, locked with tension pin)
Through Valve
3-Way Valve
Through Valve
Closing Direction: Retracting Valve Stem
Closing Direction: Extracting Valve Stem
Adjustment of Closing Force
a = Spring Travel for Through Valve
b = Spring Travel for 3-Way Valve
s = Spring Travel
F = Closing Force
WIRING DIAGRAM
STANDARD EQUIPMENT
- 2 position switches
- Handwheel with indicator
for operating direction
- Mechanical position indicator
- 2 cable glands M20 x 1,5,
for cable diameters 8-13 mm
- Central main frame for
fitting accessories
M
2
M
1
=
F
3
1
2
4
6
5
X6
L
R
S
0
1
2
4
6
7
X5
Potentiometer 1
Potentiometer 1
Additional
Zusatzwegschalter
Additional
12V/24V DC
Zu / Close
Auf / Open
Position Switch
1
4
1
5
1
6
X4
Weg /
Position
1
3
1
4
1
5
1
6
1
1
1
2
1
7
1
8
1
9
2
0
X5
L
R
S
Potentiometer 2
Potentiometer 2
Additional
1
2
3
X9
t
Weg /
Position
t
P
E
L3
L1
L
2
N
1
2
4
X5
P
E
N
L
2
L
1
t
3-Phasen Drehstrom
1-Phasen Wechselstrom
1
2
X8
Heizung
Heating
t
Weg /
Position
3-Phase a.c.
1-Phase a.c.
Index B
Zu /
Close
Auf /
Open
PS Automation GmbH
DB_PSL202_0608_E
Page 2 of 2
