WIRING INFORMATION 1993 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
BLACK/YELLOW
Ignition Harness
12V IGNITION WIRE
RED
Ignition Harness
12V ACCESSORY WIRE
RED/YELLOW
Ignition Harness
STARTER WIRE
BLUE/RED
Ignition Harness
PARKING LIGHTS (+)
RED/BLUE
Near Underdash Light In A Gray Connector
DOOR TRIGGER (-)
RED/BLACK
Near Underdash Light In A Brown
Connector
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE/RED
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE/RED
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
WHITE/GREEN
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
WHITE/RED
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
WHITE/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
BLUE/BLACK
Harness In Driver’s Kick From Driver Door
WIRING INFORMATION 1994 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
BLACK/YELLOW
Ignition Harness
12V IGNITION WIRE
RED
Ignition Harness
12V ACCESSORY WIRE
RED/YELLOW
Ignition Harness
STARTER WIRE
BLUE/RED
Ignition Harness
PARKING LIGHTS (+)
RED/BLUE
Near Underdash Light In A Gray Connector
DOOR TRIGGER (-)
RED/BLACK
Near Underdash Light In A Brown
Connector
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE/RED
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE/RED
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
WHITE/GREEN
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
WHITE/RED
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
WHITE/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
BLUE/BLACK
Harness In Driver’s Kick From Driver Door
WIRING INFORMATION 1995 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
BLACK/YELLOW
Ignition Harness
12V IGNITION WIRE
RED
Ignition Harness
12V ACCESSORY WIRE
RED/YELLOW
Ignition Harness
STARTER WIRE
BLUE/RED
Ignition Harness
PARKING LIGHTS (+)
RED/BLUE
Near Underdash Light In A Gray Connector
DOOR TRIGGER (-)
RED/BLACK
Near Underdash Light In A Brown
Connector
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE/RED
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE/RED
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
WHITE/GREEN
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
WHITE/RED
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
WHITE/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
BLUE/BLACK
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
3
WIRING INFORMATION 1996 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
BLACK/YELLOW
Ignition Harness
12V IGNITION WIRE
RED
Ignition Harness
12V ACCESSORY WIRE
RED/YELLOW
Ignition Harness
STARTER WIRE
BLUE/RED
Ignition Harness
PARKING LIGHTS (+)
RED/BLUE
Near Underdash Light In A Gray Connector
DOOR TRIGGER (-)
RED/BLACK
Near Underdash Light In A Brown
Connector
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE/RED
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE/RED
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
WHITE/GREEN
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
WHITE/RED
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
WHITE/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
BLUE/BLACK
Harness In Driver’s Kick From Driver Door
WIRING INFORMATION 1997 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
BLACK/YELLOW
Ignition Harness
12V IGNITION WIRE
RED
Ignition Harness
12V ACCESSORY WIRE
RED/YELLOW
Ignition Harness
STARTER WIRE
BLUE/RED
Ignition Harness
PARKING LIGHTS (+)
RED/BLUE
Near Underdash Light In A Gray Connector
DOOR TRIGGER (-)
RED/BLACK
Near Underdash Light In A Brown
Connector
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE/RED
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
WHITE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
WHITE/GREEN
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
WHITE/RED
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
WHITE/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
WHITE/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
BLUE/BLACK
Harness In Driver’s Kick From Driver Door
WIRING INFORMATION 1998 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
12V IGNITION WIRE
GREEN
Ignition Harness
12V ACCESSORY WIRE
YELLOW
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
POWER DOOR LOCK (-)
BLUE/GREEN
Harness In Driver’s Kick Panel
POWER DOOR UNLOCK (-)
YELLOW or YELLOW/RED
Harness In Driver’s Kick Panel
PARKING LIGHTS (+)
RED/YELLOW
Harness In Driver’s Kick Panel
DOOR TRIGGER (-)
YELLOW
At Passenger Door Pin
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE/RED
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
RED/GREEN
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
BLACK/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GREEN/YELLOW
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
GREEN/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
BLUE/WHITE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
GREEN/WHITE
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
4
WIRING INFORMATION 1999 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
12V IGNITION WIRE
GREEN
Ignition Harness
12V ACCESSORY WIRE
YELLOW
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
POWER DOOR LOCK (-)
BLUE/GREEN
Harness In Driver’s Kick Panel
POWER DOOR UNLOCK (-)
YELLOW or YELLOW/RED
Harness In Driver’s Kick Panel
PARKING LIGHTS (+)
RED/YELLOW
Harness In Driver’s Kick Panel
DOOR TRIGGER (-)
YELLOW
At Passenger Door Pin
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE/RED
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
RED/GREEN
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
BLACK/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
GREEN/YELLOW
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
GREEN/BLACK
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
BLUE/WHITE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
GREEN/WHITE
Harness In Driver’s Kick From Driver Door
WIRING INFORMATION 2000 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
12V IGNITION WIRE
GREEN
Ignition Harness
12V ACCESSORY WIRE
YELLOW
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
POWER DOOR LOCK (-)
BLUE/GREEN
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
POWER DOOR UNLOCK (-)
YELLOW or YELLOW/RED
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
PARKING LIGHTS (+)
ORANGE
At Light Switch
DOOR TRIGGER (-)
YELLOW
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE or RED/GREEN
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE/RED
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
RED/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
BLACK/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
BLUE/YELLOW
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
GREEN/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
BLUE/WHITE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
GREEN/WHITE
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
5
WIRING INFORMATION 2001 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
12V IGNITION WIRE
GREEN
Ignition Harness
12V ACCESSORY WIRE
YELLOW
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
POWER DOOR LOCK (-)
BLUE/GREEN
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
POWER DOOR UNLOCK (-)
YELLOW or YELLOW/RED
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
PARKING LIGHTS (+)
ORANGE
At Light Switch
DOOR TRIGGER (-)
YELLOW
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE or RED/GREEN
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE/RED
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
RED/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
BLACK/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
BLUE/YELLOW
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
GREEN/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
BLUE/WHITE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
GREEN/WHITE
Harness In Driver’s Kick From Driver Door
WIRING INFORMATION 2002 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
12V IGNITION WIRE
GREEN
Ignition Harness
12V ACCESSORY WIRE
YELLOW
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
POWER DOOR LOCK (-)
BLUE/GREEN
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
POWER DOOR UNLOCK (-)
YELLOW or YELLOW/RED
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
PARKING LIGHTS (+)
ORANGE
At Light Switch
DOOR TRIGGER (-)
YELLOW
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE or RED/GREEN
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE/RED
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
RED/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
BLACK/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
BLUE/YELLOW
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
GREEN/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
BLUE/WHITE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
GREEN/WHITE
Harness In Driver’s Kick From Driver Door
Copyright 2002-2004 Triple S Customs
6
WIRING INFORMATION 2003 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
12V IGNITION WIRE
GREEN
Ignition Harness
12V ACCESSORY WIRE
YELLOW
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
POWER DOOR LOCK (-)
BLUE/GREEN
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
POWER DOOR UNLOCK (-)
YELLOW or YELLOW/RED
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
PARKING LIGHTS (+)
ORANGE
At Light Switch
DOOR TRIGGER (-)
YELLOW
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE or RED/GREEN
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE/RED
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
RED/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
BLACK/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
BLUE/YELLOW
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
GREEN/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
BLUE/WHITE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
GREEN/WHITE
Harness In Driver’s Kick From Driver Door
WIRING INFORMATION 2004 Subaru Impreza
WIRE
WIRE COLOR
LOCATION
12V CONSTANT WIRE
WHITE
Ignition Harness
12V IGNITION WIRE
GREEN
Ignition Harness
12V ACCESSORY WIRE
YELLOW
Ignition Harness
STARTER WIRE
WHITE/BLACK
Ignition Harness
POWER DOOR LOCK (-)
BLUE/GREEN
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
POWER DOOR UNLOCK (-)
YELLOW or YELLOW/RED
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
PARKING LIGHTS (+)
ORANGE
At Light Switch
DOOR TRIGGER (-)
YELLOW
At Factory Keyless Entry Module Under
Dash Left Of Steering Column
TRUNK TRIGGER (-)
YELLOW/BLUE
At Light In Trunk
TACHOMETER
BLUE or RED/GREEN
At Ignition Coil
BRAKE WIRE (+)
WHITE/BLACK
At Brake Pedal Switch
HORN TRIGGER (-)
RED/GREEN
Harness At Steering Column
LEFT FRONT WINDOW UP
BLUE/RED
At Driver Window Motor Inside Door
LEFT FRONT WINDOW DOWN
BLUE
At Driver Window Motor Inside Door
RIGHT FRONT WINDOW UP
RED/BLUE
Harness In Driver’s Kick From Driver Door
RIGHT FRONT WINDOW DOWN
BLACK/BLUE
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW UP
BLUE/YELLOW
Harness In Driver’s Kick From Driver Door
LEFT REAR WINDOW DOWN
GREEN/YELLOW
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW UP
BLUE/WHITE
Harness In Driver’s Kick From Driver Door
RIGHT REAR WINDOW DOWN
GREEN/WHITE
Harness In Driver’s Kick From Driver Door
Wyszukiwarka
Podobne podstrony:
DODGE INTREPID 1993 2004
LEXUS GS300 1993 2004
SUBARU IMPREZA WRC
CHRYSLER CONCORDE 1993 2004
Eurocode 3 Part 1,5 prEN 1993 1 5 2004 (Juin 2004)
Eurocode 3 Part 5 prEN 1993 5 (2004 Jul)
FORD RANGER 1993 2004
Eurocode 3 Part 5 prEN 1993 5 (2004 Jul)
akumulator do subaru impreza gd gg 16i 20i 16v 20i turbo wr
akumulator do subaru impreza 15 i 20 i 25 sti 25 wrx 25 i
akumulator do subaru impreza gfc 16 16 4wd 20 4wd 20 turbo 4
akumulator do subaru impreza gc 16i 16i 4wd 18i 4wd 20i 4wd
SUBARU IMPREZA 1997(1)
więcej podobnych podstron
