Steering wheel Control Switch

background image

2009 Chevrolet Aveo

|

Aveo, Wave, G3, Barina (VIN S/T) Service Manual

|

Driver Information and Entertainment

|

Secondary and Configurable Customer Controls

|

Repair Instructions

| Document ID: 2093614

Steering Wheel Control Switch Assembly Replacement

Removal Procedure

Warning:

Refer to

Battery Disconnect Warning

in the Preface section.

1. Disconnect the negative battery cable.
2. Remove the screws and the audio remote controller.

Installation Procedure

© 2010 General Motors Corporation. All rights reserved.

Page 1 of 2

Document ID: 2093614

7/5/2010

http://localhost:9001/si/showDoc.do?docSyskey=2093614&pubCellSyskey=148742&pubO...

background image

1. Install the audio remote controller with the screws.
2. Connect the negative battery cable.

Page 2 of 2

Document ID: 2093614

7/5/2010

http://localhost:9001/si/showDoc.do?docSyskey=2093614&pubCellSyskey=148742&pubO...
