user manual OPEL CD 70 NAVI E

background image

You can read the recommendations in the user guide, the technical guide or the installation guide for OPEL CD 70 NAVI. You'll
find the answers to all your questions on the OPEL CD 70 NAVI in the user manual (information, specifications, safety advice,
size, accessories, etc.). Detailed instructions for use are in the User's Guide.

User manual OPEL CD 70 NAVI

User guide OPEL CD 70 NAVI

Operating instructions OPEL CD 70 NAVI

Instructions for use OPEL CD 70 NAVI

Instruction manual OPEL CD 70 NAVI

Your user manual
OPEL CD 70 NAVI

background image

Manual abstract:

the contrast of the display can be set in the "System Settings" menu , see Page 113 and vehicle operating instructions. Symbols in the main display After the

Infotainment System has been switched on, various symbols can be displayed depending on the selected functional unit (audio, navigation, trip computer 3).

Traffic Programme is active, however no TP station is being received. Under bridges, in the forest or between high buildings). Trip computer function The

symbols of the trip computer are described in the vehicle operating instructions. The extensive functions of the Infotainment System are controlled using

function buttons and menus. The steering wheel remote control 3 allows you to safely and conveniently operate the Infotainment System without having to take

your hands off the steering wheel. When the Infotainment System is switched on, the last selected volume is set if this is lower than the maximum start-up

volume. It controls almost all the system functions by means of menus. You will hear the last audio source selected.

When the unit is switched off and the ignition is switched on, time, outside temperature and date are displayed. When navigation is active you will continue to

hear the voice announcements. Switching on and off with the ignition key (ignition logic) If the Infotainment System is switched on, it can be switched off and

on automatically by removing or inserting and turning the ignition key. Press P rotary control again, turn P rotary control to cancel the mute function. If the

Infotainment System was switched on via the P rotary control, it switches off automatically one hour after the ignition key is removed.

It can be recalled at any time from a different menu display using the MAIN button 5. It shows the three main functions: Turn the click dial to call up the

display of the required function. Waveband, station name or frequency or CD track and track number, etc. The following information is displayed in all

functions of the main page: Outside temperature, Time of day, Information on the climate control system 3. When the Infotainment System is switched off

and the ignition is switched on, outside temperature, time of day and date are displayed.

Feature pages Feature pages are menu pages where you stay, e. g. When you are listening to the radio or a CD. Feature pages also have menu items that can

be executed and that will lead you to further feature or settings pages. Settings pages Settings pages are menu pages where you can make settings, e. Menu

levels The menus of the Infotainment System are divided into levels. The current menu level is shown by vertical lines at the left-hand side of the screen (e. g.

Main display = no line, Radio feature page = 1 line, etc. The different pages have different functionalities: Selection pages Selection pages have a selection

menu with a preview of each menu item on the left margin of the screen.

Move cursor to the desired menu item by turning the click dial. For some menu items settings are made after selecting them by turning the click dial. By

turning the click dial the menu items available in a menu can be selected. Each selected menu item has an inverse field designated as the cursor. Many of the

available functions are executed directly by pressing the click dial. Some open a submenu with further functions. each menu has the hidden "Return" menu

item. This menu item only becomes visible if you get to the top end of a menu (turn click dial anti-clockwise). This menu item only becomes visible if you get to

the bottom end of a menu (turn click dial clockwise). This function can also be executed at any time by pressing the MAIN button 5.

The main functions are recalled using the NAVI, AUDIO, SOUND and BC buttons. For some menu items lists are called up. You can navigate these lists using

the cursor. In certain cases the display shows additional notes and information of the Infotainment System or other vehicle components as a pop-up. For this

purpose, the currently displayed menu is overlaid with the pop-up.

You have to confirm some of the pop-ups (e. g. The safety warnings of the navigation), others will automatically disappear after a short period..
