ISUZU HOMBRE 1996-2000

V

V

E

E

H

H

I

I

C

C

L

L

E

E

W

W

I

I

R

R

I

I

N

N

G

G

Copyright 2002-2004 Triple S Customs

2

WIRING INFORMATION: 1996 Isuzu Hombre

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition harness

STARTER WIRE

PURPLE

Ignition harness

12V IGNITION WIRE

PINK

Ignition harness

SECOND 12V IGNITION WIRE

PINK/WHITE or WHITE

Ignition harness

12V ACCESSORY WIRE

ORANGE

Ignition harness

POWER DOOR LOCK (positive trigger on
vehicles with OEM keyless entry, 5-wire
reverse polarity on vehicles without OEM
keyless entry)

LT.BLUE

Harness Coming Into Vehicle From Driver’s
Door Or Module Attached To Under Dash
Panel

POWER DOOR UNLOCK (positive trigger on
vehicles with OEM keyless entry, 5-wire
reverse polarity on vehicles without OEM
keyless entry)

WHITE

Harness Coming Into Vehicle From Driver’s
Door Or Module Attached To Under Dash
Panel

PARKING LIGHTS (+)

BROWN

Headlight Switch

DOOR TRIGGER (-)

WHITE or BLACK

Under Dash Light, Door Pin, Or Module
Attached To Under Dash Panel

TACHOMETER WIRE

WHITE

4.3L models- Engine Control Module On
Driver’s Inner Fender
2.2L models- Engine Control Module On
Passenger’s Inner Fender

BRAKE WIRE (+)

WHITE

Brake pedal switch

HORN TRIGGER (-)

BLACK

Steering column

LEFT FRONT WINDOW UP

DARK BLUE

At Window Switch Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW UP

DK.BLUE/WHITE

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW DOWN

TAN

At Window Switch Inside Driver’s Door

WIRING INFORMATION: 1997 Isuzu Hombre

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition harness

STARTER WIRE

PURPLE

Ignition harness

12V IGNITION WIRE

PINK

Ignition harness

SECOND 12V IGNITION WIRE

PINK/WHITE or WHITE

Ignition harness

12V ACCESSORY WIRE

ORANGE

Ignition harness

POWER DOOR LOCK (positive trigger on
vehicles with OEM keyless entry, 5-wire
reverse polarity on vehicles without OEM
keyless entry)

LT.BLUE

Harness Coming Into Vehicle From Driver’s
Door Or Module Attached To Under Dash
Panel

POWER DOOR UNLOCK (positive trigger on
vehicles with OEM keyless entry, 5-wire
reverse polarity on vehicles without OEM
keyless entry)

WHITE

Harness Coming Into Vehicle From Driver’s
Door Or Module Attached To Under Dash
Panel

PARKING LIGHTS (+)

BROWN

Headlight Switch

DOOR TRIGGER (-)

WHITE or BLACK

Under Dash Light, Door Pin, Or Module
Attached To Under Dash Panel

TACHOMETER WIRE

WHITE

4.3L models- Engine Control Module On
Driver’s Inner Fender
2.2L models- Engine Control Module On
Passenger’s Inner Fender

BRAKE WIRE (+)

WHITE

Brake pedal switch

HORN TRIGGER (-)

BLACK

Steering column

LEFT FRONT WINDOW UP

DARK BLUE

At Window Switch Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW UP

DK.BLUE/WHITE

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW DOWN

TAN

At Window Switch Inside Driver’s Door

Copyright 2002-2004 Triple S Customs

3

WIRING INFORMATION: 1998 Isuzu Hombre

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

12V IGNITION WIRE

PINK

Ignition Harness

SECOND 12V IGNITION WIRE

WHITE

Ignition Harness

12V ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT.BLUE

Module Under Dash To Right Of Accelerator
Pedal

POWER DOOR UNLOCK (+)

WHITE

Module Under Dash To Right Of Accelerator
Pedal

PARKING LIGHTS (+)

BROWN

Module Under Dash To Right Of Accelerator
Pedal

DOOR TRIGGER (-)

TAN (driver’s door)
ORANGE (pass. door)

Module Under Dash To Right Of Accelerator
Pedal

FACTORY ALARM DISARM (-)

LT.GREEN

Harness In Driver’s Kick Panel Or Module
Under Dash To Right Of Accelerator Pedal

TACHOMETER WIRE

WHITE

Grey Module On Passenger Inner Fender

BRAKE WIRE (+)

WHITE

Plug At Brake Pedal Switch Or Harness
Running Down Under Carpet

HORN TRIGGER (-)

BLACK

Module Under Dash To Right Of Accelerator
Pedal

LEFT FRONT WINDOW UP

DARK BLUE

At Window Switch Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW UP

DK.BLUE/WHITE

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW DOWN

TAN

At Window Switch Inside Driver’s Door

This vehicle is equipped with a Pass-Lock II anti-theft system. This must be bypassed when installing a remote start system.


WIRING INFORMATION: 1999 Isuzu Hombre

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

12V IGNITION WIRE

PINK

Ignition Harness

SECOND 12V IGNITION WIRE

WHITE

Ignition Harness

12V ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT.BLUE

Module Under Dash To Right Of Accelerator
Pedal

POWER DOOR UNLOCK (+)

WHITE

Module Under Dash To Right Of Accelerator
Pedal

PARKING LIGHTS (+)

BROWN

Module Under Dash To Right Of Accelerator
Pedal

DOOR TRIGGER (-)

TAN (driver’s door)
ORANGE (pass. door)

Module Under Dash To Right Of Accelerator
Pedal

FACTORY ALARM DISARM (-)

LT.GREEN

Harness In Driver’s Kick Panel Or Module
Under Dash To Right Of Accelerator Pedal

TACHOMETER WIRE

WHITE

Grey Module On Passenger Inner Fender

BRAKE WIRE (+)

WHITE

Plug At Brake Pedal Switch Or Harness
Running Down Under Carpet

HORN TRIGGER (-)

BLACK

Module Under Dash To Right Of Accelerator
Pedal

LEFT FRONT WINDOW UP

DARK BLUE

At Window Switch Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW UP

DK.BLUE/WHITE

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW DOWN

TAN

At Window Switch Inside Driver’s Door

This vehicle is equipped with a Pass-Lock II anti-theft system. This must be bypassed when installing a remote start system.

Copyright 2002-2004 Triple S Customs

4

WIRING INFORMATION: 2000 Isuzu Hombre

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition Harness

STARTER WIRE

YELLOW

Ignition Harness

12V IGNITION WIRE

PINK

Ignition Harness

SECOND 12V IGNITION WIRE

WHITE

Ignition Harness

12V ACCESSORY WIRE

ORANGE

Ignition Harness

POWER DOOR LOCK (+)

LT.BLUE

Module Under Dash To Right Of Accelerator
Pedal

POWER DOOR UNLOCK (+)

WHITE

Module Under Dash To Right Of Accelerator
Pedal

PARKING LIGHTS (+)

BROWN

Module Under Dash To Right Of Accelerator
Pedal

DOOR TRIGGER (-)

TAN (driver’s door)
ORANGE (pass. door)

Module Under Dash To Right Of Accelerator
Pedal

FACTORY ALARM DISARM (-)

LT.GREEN

Harness In Driver’s Kick Panel Or Module
Under Dash To Right Of Accelerator Pedal

TACHOMETER WIRE

WHITE

Grey Module On Passenger Inner Fender

BRAKE WIRE (+)

WHITE

Plug At Brake Pedal Switch Or Harness
Running Down Under Carpet

HORN TRIGGER (-)

BLACK

Module Under Dash To Right Of Accelerator
Pedal

LEFT FRONT WINDOW UP

DARK BLUE

At Window Switch Inside Driver’s Door

LEFT FRONT WINDOW DOWN

BROWN

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW UP

DK.BLUE/WHITE

At Window Switch Inside Driver’s Door

RIGHT FRONT WINDOW DOWN

TAN

At Window Switch Inside Driver’s Door

This vehicle is equipped with a Pass-Lock II anti-theft system. This must be bypassed when installing a remote start system.
