Body Closures - Front Door Alignment

Mondeo 2007.5 (02/2007-)

Print

General Procedures

1. Refer to:

Instrument Panel - Vehicles With: Automatic Temperature Control

(501-12 Instrument Panel and Console,

Removal and Installation).
Refer to:

Instrument Panel - Vehicles With: Manual Temperature Control

(501-12 Instrument Panel and Console,

Removal and Installation).

2.

3. Loosen one complete turn.

4.

5.

1. Loosen one complete turn.

6. Torque: 35 Nm

7. Torque: 35 Nm

8.

9.

Strona 1 z 2

2012-08-11

http://127.0.0.1:8888/wsm/js/procedure.do?variantId=1449&proc-uid=G860112&gui...

10. Loosen one complete turn.

11.

12. Torque: 20 Nm

13.

14. Refer to:

Instrument Panel - Vehicles With: Automatic Temperature Control

(501-12 Instrument Panel and Console,

Removal and Installation).
Refer to:

Instrument Panel - Vehicles With: Manual Temperature Control

(501-12 Instrument Panel and Console,

Removal and Installation).

Strona 2 z 2

2012-08-11
