5. MAIN Electrical Parts List

5-1

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

SEC CODE

Design Location

Description

D7000,ZD5000

0403-002001

UFZVTE-175.6B

D5001

0404-001250

RB520G-30

D5000,D5002

0404-001887

KDR582F

D6000,D6001,D6002

0406-001223

PG05DBTFC

D6003,D6004,D6005

0406-001223

PG05DBTFC

ZD6004,ZD7008,ZD7009

0406-001223

PG05DBTFC

ZD9000

0406-001223

PG05DBTFC

ZD7001,ZD7002,ZD7003

0406-001267

RCLAMP0521P

ZD7004,ZD7005,ZD7010

0406-001267

RCLAMP0521P

ZD7011,ZD7012,ZD7013

0406-001267

RCLAMP0521P

ZD7014,ZD7015,ZD7016

0406-001413

PESD5V0F1BL

ZD7017,ZD7018

0406-001413

PESD5V0F1BL

ZD6005,ZD6006,ZD6007

0406-001494

RCLAMP0531T

ZD6008,ZD6009,ZD6010

0406-001494

RCLAMP0531T

ZD5001,ZD5002

0406-001505

PESD5V0X1UALD

ZD7000

0406-001569

UCLAMP0511T

ZD7007

0406-001592

PESD5V0V1BDSF

TR5000

0505-002088

2SK3541

Q5000,Q7001

0505-002341

SI1013X-T1-GE3

Q9000

0505-002384

PMR280UN

Q6000,Q6001

0505-003234

PMZB290UN

LED5000

0601-003398

SPFCW13301CRS1D2T0

U5005,U5006,U5008

0801-003228

TC7SG17AFS

U1010

0801-003437

NL17SG32P5T5G

UCP4000

0902-003074

SC55420BFB-A03S

U5004

1001-001394

NLAS5123MNR2G

U1002,U1004,U1005

1001-001774

XM0831SH-DL0601

U9005

1009-001066

S-5712CCDL1-I4T1U

UME4000

1107-002297

THGBMBG7D2KBAIL

PAM1000

1201-003642

SKY77622

PAM1001

1201-003645

SKY77778

U2000

1201-003729

BGU8019W

U1003

1201-003793

BGU8M1

U6000

1202-001120

NCX2200GM

U5002

1203-002250

R3111Q281C

U6002,U6003,U8000

1203-004819

RP103K281D-TR

U8001

1203-004819

RP103K281D-TR

C2014,R3016

1203-006766

NCP367OPMUEOTBG

U9003

1203-006767

RP152L006B-TR

U5009

1203-007294

RP114K331D-TR

U1007

1203-007766

SKY87000

U5003

1203-007790

MIC5362-3.3YMT

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-2

U8004

1203-007961

TPS65633RTER

U7000

1203-008004

MAX14681EWC-T

U5001

1203-008158

S2MPS11B02-6430

U5000

1203-008172

S2ABB01X01-6030

U5007

1203-008193

MAX77888GEWJ+T

U8002

1203-008217

TPS65630ARTGR

U8003

1205-004753

SII8240BOC

U6001

1205-004772

WM5102ECS

UCP3000

1205-004863

PMB9923

U1008

1205-004884

PMB5740.P10

U9004

1205-004916

FPF2195BUCX

U2002

1205-005012

BCM4354XKUBG

U2001

1205-005016

BCM47531A1IUB2G

U7001

1205-005097

ET3152

U9002

1209-002245

AK09911C

U9001

1209-002246

BMI055

U1009

1209-002252

SX9500IULTRT

U9000

1301-002167

ICE40LP640-SWG16TR

TH4000,TH4001,TH4002

1404-001694

NCP15WB473F03RC

TH3000

1404-001728

NCP03WB473J05RL

R1005

2007-000169

TSR16GJ514V

R9000,R9001,R9002

2007-000174

MCR01MZP5J470

R9003,R9004,R9005

2007-000174

MCR01MZP5J470

R9006,R9007,R9008

2007-000174

MCR01MZP5J470

R9009

2007-000174

MCR01MZP5J470

R4080,R4109

2007-001308

RC1005J201CS

R5002

2007-003015

MCR01MZP5J2R2

R3014

2007-007107

RC1005F104CS

R4086,R4088

2007-007136

RC1005F472CS

R8003

2007-007139

MCR01MZP5F4702

R1030,R5015

2007-007142

RC1005F103CS

R4049,R4051,R4065

2007-007312

MCR01MZP5F2002

R4067,R4098,R4099

2007-007312

MCR01MZP5F2002

R4100,R4102

2007-007312

MCR01MZP5F2002

R4069,R4070,R4078

2007-007517

MCR01MZP5F2400

R4079,R4096,R4097

2007-007517

MCR01MZP5F2400

R9018

2007-007627

RK73H1ETP1602F

R4083,R6019,R6020

2007-007741

M5534204B10E0R

R8006

2007-007741

M5534204B10E0R

R4008,R4117

2007-007942

RC1005F105CS

R4118

2007-007946

470K,1%

R1015,R1016,R5010

2007-008045

ERJ1GEJ101C

R5011,R7019

2007-008045

ERJ1GEJ101C

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-3

R7023

2007-008049

MCR006YZPJ202

R7026

2007-008051

RC0603J332CS

R4047,R4048,R4066

2007-008052

ERJ1GENJ472X

R5016,R5022,R7015

2007-008052

ERJ1GENJ472X

R8004,R8005,R8007

2007-008052

ERJ1GENJ472X

R9012,R9013

2007-008052

ERJ1GENJ472X

R2000,R3015,R4031

2007-008055

ERJ1GENJ104X

R4032,R4034,R4035

2007-008055

ERJ1GENJ104X

R4036,R4038,R4082

2007-008055

ERJ1GENJ104X

R7022,R7024

2007-008055

ERJ1GENJ104X

R1001,R1002,R7011

2007-008057

MCR006YZPJ151

R5020

2007-008403

RC1005F364CS

R3019,R3024,R5000

2007-008419

ERJ1GEJ102C

R5001

2007-008419

ERJ1GEJ102C

R5013,R5017,R5018

2007-008420

RMC-1/20-330JPA

R5024,R6002

2007-008420

RMC-1/20-330JPA

R4019,R4020

2007-008478

RMC1/20152JPA

R2007,R2008,R2009

2007-008483

RMC1/20473JPA

R2010,R2011,R7001

2007-008483

RMC1/20473JPA

R7002,R7003,R7004

2007-008483

RMC1/20473JPA

R5003,R5004,R5019

2007-008486

ERJ1GEJ204C

R3026,R4000,R4003

2007-008516

ERJ1GEJ103C

R4005,R4007,R4022

2007-008516

ERJ1GEJ103C

R4026,R4027,R4064

2007-008516

ERJ1GEJ103C

R4084,R4103,R4104

2007-008516

ERJ1GEJ103C

R4105,R4106,R4107

2007-008516

ERJ1GEJ103C

R4108,R4112,R4113

2007-008516

ERJ1GEJ103C

R4115,R5014,R6023

2007-008516

ERJ1GEJ103C

R6030,R7005,R7021

2007-008516

ERJ1GEJ103C

R7025,R9010,R9011

2007-008516

ERJ1GEJ103C

R9014,R9015

2007-008516

ERJ1GEJ103C

R4052,R4077,R8002

2007-008531

MCR006MZPJ0100

R2005

2007-008579

RMC1/20221JPA

R1022,R1023,R1024

2007-008588

MCR006YZPJ222

R1025,R1026,R3007

2007-008588

MCR006YZPJ222

R3008,R3009

2007-008588

MCR006YZPJ222

R7012,R7014

2007-008774

RC0603J2R2CS

R5009

2007-008798

MCR006YZPJ153

R1006,R1028

2007-008806

RC0603J510CS

R5005,R5021,R6004

2007-009084

MCR006YZPJ105

R6017,R6018,R7000

2007-009084

MCR006YZPJ105

R4068,R7006

2007-009111

RC0603J220CS

R2001,R3017,R7017

2007-009155

MCR006YZPJ474

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-4

R4072,R4073,R4074

2007-009157

MCR006YZPF1003

R4075,R4076,R4089

2007-009157

MCR006YZPF1003

R4090,R4091,R4092

2007-009157

MCR006YZPF1003

R4093,R4094,R4095

2007-009157

MCR006YZPF1003

R9016

2007-009157

MCR006YZPF1003

R4053,R4055,R4056

2007-009171

MCR006YZPJ513

R4057,R4058,R4059

2007-009171

MCR006YZPJ513

R4060,R4061,R4062

2007-009171

MCR006YZPJ513

R1000,R3013

2007-009199

MCR006YZPJ360

R6000

2007-009212

MCR006YZPF1001

R6003

2007-009223

ERJ1GEF3323C

R3025

2007-009233

MCR006YZPJ514

R1003

2007-009361

MCR006YZPJ304

R4009,R4010,R4011

2007-009408

ERJ1GEF222C

R4012,R4013,R4014

2007-009408

ERJ1GEF222C

R4015,R4016,R4017

2007-009408

ERJ1GEF222C

R4018,R4039,R4040

2007-009408

ERJ1GEF222C

R4041,R4042,R4043

2007-009408

ERJ1GEF222C

R4044

2007-009408

ERJ1GEF222C

R1032

2007-009805

RC0603F510CS

R3012

2007-009920

RC0603F241CS

R6001

2007-009969

MCR006YZPF1201

R3021

2007-010233

RC1005F4021CS

R5023

2007-011511

ACR0805T0R01F-0R01

R7010

2007-011648

RC0603F1R0CS

L1002

2203-000233

GRP1555C1H101J

C1011

2203-000278

GRP1555C1H100D

C7011,C9003,C9005

2203-000386

GRP1555C1H150J

C6019,C6046,C6047

2203-000425

GRP1555C1H180J

C7001

2203-000438

GRP155R71H102K

C4099,C4100

2203-000489

GRP155R71H222K

C2043,C5103

2203-000725

GRP155R71H392KA01E

C6042

2203-000854

GRP1555C1H390J

C5083,C5086,C5087

2203-000995

GRP1555C1H470J

C6040,C7012

2203-001072

GRP1555C1H560JD01E

C6018,C6044,C6045

2203-001239

GRP1555C1H820JD01E

C6051,C6052,C6053

2203-001239

GRP1555C1H820JD01E

C6054

2203-001239

GRP1555C1H820JD01E

C1000

2203-001259

GRP1555C1H8R0DZ01E

C1114

2203-001383

GRP1555C1HR50C

C1002

2203-002677

CL05CR75BB5NNNC

C5082,C5084,C5085

2203-002687

GRP155R71H122KD01E

C2103,C6058

2203-005682

GRP0335C1E330JD01E

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-5

C1030,C7016,C7017

2203-005717

GRP0335C1E270JD01E

C7018

2203-005717

GRP0335C1E270JD01E

C2005,C3060,C3063

2203-005725

GRP0335C1E220JD01E

C5028,C5055

2203-005725

GRP0335C1E220JD01E

C1106

2203-005726

GRM0335C1E560J

C1004,C2066,C5102

2203-005727

CL03C120JA3GNNC

C1006,C1009,C6016

2203-005729

CL03C150JAGC

C6039,C9004,C9006

2203-005729

CL03C150JAGC

C4000,C4001,C6056

2203-005731

GRM0335C1E180J

C6057

2203-005731

GRM0335C1E180J

C7005

2203-005734

GRM0335C1E820JD01D

C1001,C1019,C1041

2203-005736

GRP0335C1E101JD01E

C1043,C1075,C1085

2203-005736

GRP0335C1E101JD01E

C1086,C1087,C1088

2203-005736

GRP0335C1E101JD01E

C1093,C1099,C1100

2203-005736

GRP0335C1E101JD01E

C1107,C1112,C1113

2203-005736

GRP0335C1E101JD01E

C1119,C1124,C1127

2203-005736

GRP0335C1E101JD01E

C1149,C1150,C2010

2203-005736

GRP0335C1E101JD01E

C2012,C2032,C2033

2203-005736

GRP0335C1E101JD01E

C2093,L1015,L1045

2203-005736

GRP0335C1E101JD01E

L1068

2203-005736

GRP0335C1E101JD01E

C1016,C1017,C1024

2203-005777

CL03C010CA3GNNC

C1026,C2011,C2044

2203-005777

CL03C010CA3GNNC

C2054,C2096,L2030

2203-005777

CL03C010CA3GNNC

C1013,C1014,U9107

2203-005789

ECJZEC1E0R5B

C1028

2203-005792

CL03C1R5CA3GNNC

C2008

2203-005806

GRP033R71C102KD01E

C4093,C4098,C5068

2203-006048

GRM155R71A104K

C8015

2203-006048

GRM155R71A104K

C1129,C2047,C2095

2203-006194

GRP033R70J103KA01E

C5081

2203-006194

GRP033R70J103KA01E

C2018,C2065,C2068

2203-006305

CM03CG100J25AH

C2072,C2074,C2075

2203-006305

CM03CG100J25AH

C2076,C2077,C2078

2203-006305

CM03CG100J25AH

C2079,C2080,C2081

2203-006305

CM03CG100J25AH

C2082,C2083,C2084

2203-006305

CM03CG100J25AH

C2085,C2086,C2087

2203-006305

CM03CG100J25AH

C2088,C2090,C6017

2203-006305

CM03CG100J25AH

L2009

2203-006305

CM03CG100J25AH

C5022,C6037,C6048

2203-006399

GRM155R60J105KE19D

C6049,C7014

2203-006399

GRM155R60J105KE19D

C1010,C1029,C1039

2203-006400

GRM033R71E102K

C1063,C1065,C1108

2203-006400

GRM033R71E102K

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-6

C1118,C1135

2203-006400

GRM033R71E102K

C1033,C1034,C1035

2203-006423

GRM33X5R104K6.3

C1038,C1053,C1054

2203-006423

GRM33X5R104K6.3

C1064,C1067,C1068

2203-006423

GRM33X5R104K6.3

C1071,C1072,C1073

2203-006423

GRM33X5R104K6.3

C1074,C1076,C1077

2203-006423

GRM33X5R104K6.3

C1079,C1090,C2013

2203-006423

GRM33X5R104K6.3

C2034,C2035,C2067

2203-006423

GRM33X5R104K6.3

C3004,C3005,C3006

2203-006423

GRM33X5R104K6.3

C3008,C3009,C3011

2203-006423

GRM33X5R104K6.3

C3015,C3016,C3017

2203-006423

GRM33X5R104K6.3

C3018,C3019,C3020

2203-006423

GRM33X5R104K6.3

C3021,C3022,C3023

2203-006423

GRM33X5R104K6.3

C3024,C3025,C3026

2203-006423

GRM33X5R104K6.3

C3027,C3030,C3031

2203-006423

GRM33X5R104K6.3

C3032,C3033,C3034

2203-006423

GRM33X5R104K6.3

C3037,C3042,C3047

2203-006423

GRM33X5R104K6.3

C3048,C3050,C3051

2203-006423

GRM33X5R104K6.3

C3053,C4003,C4004

2203-006423

GRM33X5R104K6.3

C4007,C4011,C4013

2203-006423

GRM33X5R104K6.3

C4015,C4017,C4030

2203-006423

GRM33X5R104K6.3

C4032,C4043,C4048

2203-006423

GRM33X5R104K6.3

C4051,C4053,C4060

2203-006423

GRM33X5R104K6.3

C4064,C4066,C4068

2203-006423

GRM33X5R104K6.3

C4070,C4072,C4074

2203-006423

GRM33X5R104K6.3

C4076,C4088,C5017

2203-006423

GRM33X5R104K6.3

C5026,C5080,C5096

2203-006423

GRM33X5R104K6.3

C6007,C6008,C6009

2203-006423

GRM33X5R104K6.3

C6010,C6020,C6035

2203-006423

GRM33X5R104K6.3

C7015,C7026,C7027

2203-006423

GRM33X5R104K6.3

C8021,C8023,C8024

2203-006423

GRM33X5R104K6.3

C8026,C8028,C8029

2203-006423

GRM33X5R104K6.3

C9000,C9001,C910

2203-006423

GRM33X5R104K6.3

C911

2203-006423

GRM33X5R104K6.3

C1069,C2001,C3056

2203-006556

GRM0335C1E470JD01D

C3057

2203-006556

GRM0335C1E470JD01D

C2015,C2016,C5067

2203-006562

CV05X5R105K10AH

C5074,C5076,C6036

2203-006562

CV05X5R105K10AH

C6055,C8002,C8003

2203-006562

CV05X5R105K10AH

C8013

2203-006562

CV05X5R105K10AH

C1083,C1091

2203-006620

GRM033R71C151KD01D

C1130

2203-006648

GRM033R60J223KE01D

C1040,C1042

2203-006665

GRM0335C1E2R2CD01D

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-7

C1045,C1046

2203-006674

GRM0335C1E3R3B

C1120,C1121,C2052

2203-006707

GRM0335C1E4R7C

C2055,C2061,C2062

2203-006707

GRM0335C1E4R7C

C2063,C2064,C2099

2203-006707

GRM0335C1E4R7C

C2102

2203-006707

GRM0335C1E4R7C

C1136,C1137

2203-006824

CV105X5R475K10AT

C1142,C1143,C2009

2203-006839

CL03A104KP3NNNC

C5088,C5089,C5090

2203-006839

CL03A104KP3NNNC

C5091,C5097,C6050

2203-006839

CL03A104KP3NNNC

C7003

2203-006841

CV05X5R105K16AH

C5077,C7008

2203-006844

CV05X5R474K10AH

C1062,C3007,C3049

2203-006872

GRM155R60J225ME15D

C3052,C4005,C4041

2203-006872

GRM155R60J225ME15D

C4046,C4050,C4089

2203-006872

GRM155R60J225ME15D

C8016,C8022,C8025

2203-006872

GRM155R60J225ME15D

C8027

2203-006872

GRM155R60J225ME15D

C1080,C1081,C1096

2203-006896

GRM033R71E121KA01D

C1097,C1098,C1115

2203-006896

GRM033R71E121KA01D

C1122,C1123,C1145

2203-006896

GRM033R71E121KA01D

C7028

2203-006978

GMK107BJ105KA-T

C7002

2203-006979

CL03B103KP3NNNC

C2037,C2039,C2041

2203-007210

CV03X5R224K06AH

C3010,C3013,C3014

2203-007210

CV03X5R224K06AH

C3040,C3041,C3043

2203-007210

CV03X5R224K06AH

C3044,C3045,C3046

2203-007210

CV03X5R224K06AH

C4091,C4092

2203-007210

CV03X5R224K06AH

C5061

2203-007240

CL10A226MQ8NRNE

C3055,C3058,C7004

2203-007269

CL21A226MPCLRNC

C8011,C8012,C8019

2203-007269

CL21A226MPCLRNC

C8020,C8030

2203-007269

CL21A226MPCLRNC

C1141,C5072,C5073

2203-007270

CL10A106KP8NNNC

C7007,C8014

2203-007270

CL10A106KP8NNNC

C2000,C2003,C2025

2203-007271

CL05A225KP5NSNC

C2026,C3000,C4095

2203-007271

CL05A225KP5NSNC

C6000,C6001,C6002

2203-007271

CL05A225KP5NSNC

C6003,C6005,C6006

2203-007271

CL05A225KP5NSNC

C6026,C6027,C6028

2203-007271

CL05A225KP5NSNC

C6029,C6030,C6031

2203-007271

CL05A225KP5NSNC

C6033

2203-007271

CL05A225KP5NSNC

C5024

2203-007312

CL03A224MQ3NNNH

C2040,C4040,C4044

2203-007317

CV05X5R475M06AH

C4045,C4049,C4090

2203-007317

CV05X5R475M06AH

C5019,C7006

2203-007317

CV05X5R475M06AH

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-8

C3036,C3039,C6043

2203-007369

CL03A105KQ3CSNH

C4008,C4009,C4039

2203-007385

CL05A106MR5NRNC

C8035,C8036,C9012

2203-007385

CL05A106MR5NRNC

C9013,C9014,C9016

2203-007385

CL05A106MR5NRNC

C3012,C3035,C3054

2203-007391

CL03A474KQ3NNNH

C6032

2203-007391

CL03A474KQ3NNNH

C1031,C1032,C1061

2203-007393

CL05A475KP5NRNC

C1070,C1139,C3038

2203-007393

CL05A475KP5NRNC

C5070,C5071,C9002

2203-007393

CL05A475KP5NRNC

C1007,C1008,C2002

2203-007449

CL03A105MQ3CSNH

C2007,C2042,C3061

2203-007449

CL03A105MQ3CSNH

C3062,C4002,C4006

2203-007449

CL03A105MQ3CSNH

C4014,C4016,C4029

2203-007449

CL03A105MQ3CSNH

C4031,C4042,C4047

2203-007449

CL03A105MQ3CSNH

C4052,C4059,C4063

2203-007449

CL03A105MQ3CSNH

C4065,C4069,C4071

2203-007449

CL03A105MQ3CSNH

C4075,C4086,C4087

2203-007449

CL03A105MQ3CSNH

C4096,C5029,C5030

2203-007449

CL03A105MQ3CSNH

C5034,C5035,C5036

2203-007449

CL03A105MQ3CSNH

C5037,C5038,C5039

2203-007449

CL03A105MQ3CSNH

C5040,C5044,C5046

2203-007449

CL03A105MQ3CSNH

C5048,C5049,C5050

2203-007449

CL03A105MQ3CSNH

C5052,C5053,C5095

2203-007449

CL03A105MQ3CSNH

C5100,C5105,C5106

2203-007449

CL03A105MQ3CSNH

C6004,C6022,C6023

2203-007449

CL03A105MQ3CSNH

C6024,C6025,C6034

2203-007449

CL03A105MQ3CSNH

C8004,C8006,C8008

2203-007449

CL03A105MQ3CSNH

C8009,C9010,C9015

2203-007449

CL03A105MQ3CSNH

C9019,C9020,C9022

2203-007449

CL03A105MQ3CSNH

C9023,C9024,C9025

2203-007449

CL03A105MQ3CSNH

C3001,C3002,C3003

2203-007474

CL05A106MQ5NUNC

C5009,C5014,C5020

2203-007474

CL05A106MQ5NUNC

C5021,C5058,C5059

2203-007474

CL05A106MQ5NUNC

C5062

2203-007474

CL05A106MQ5NUNC

V1000

2203-007759

GRP1555C1H1R0BZ01E

C2021,C2022,C2023

2203-007775

CV05X5R475M10AH

C5015,C5016

2203-007775

CV05X5R475M10AH

C5056,C5063,C5069

2203-007781

CL10A226MP8NUNE

C5079

2203-007781

CL10A226MP8NUNE

C3059

2203-007795

CL05A106MP5NUNC

C2004,C2024,C2027

2203-007796

CL03A105MP3NSNC

C2029,C2030,C2100

2203-007796

CL03A105MP3NSNC

C6015,C6021,C8000

2203-007796

CL03A105MP3NSNC

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-9

C8001,C9008

2203-007796

CL03A105MP3NSNC

C5098,C5101

2203-007860

CL21A476MQMNRNR

C1078

2203-008095

CL03A224KP3NNNC

C2089

2203-008097

CL03A104KA3NNNC

C4103,C5093,C5094

2203-008126

CL05A475KP5NRNZ

C5104

2203-008126

CL05A475KP5NRNZ

C5057,C5060

2203-008199

CL10A476MR8NZNE

C5075

2203-008217

CL10A226MP8NUNR

C2006,C4010,C4012

2203-008242

CL03A225MQ3CRNC

C4058,C4067,C4073

2203-008242

CL03A225MQ3CRNC

C5031,C5032,C5033

2203-008242

CL03A225MQ3CRNC

C5043,C5045,C5047

2203-008242

CL03A225MQ3CRNC

C5051,C5054

2203-008242

CL03A225MQ3CRNC

C5027,C7023

2203-008243

CL03A103KA3NNNC

C1146,C2017,C2048

2203-008394

CL03C8R2BA3GNNC

C2050,C2057,C2058

2203-008394

CL03C8R2BA3GNNC

C2059,C2060,C2069

2203-008394

CL03C8R2BA3GNNC

C2070,C2071,L2010

2203-008394

CL03C8R2BA3GNNC

C1133,C5001,C5002

2203-008527

CL05A106MP8NUB8

C5003,C5006,C5007

2203-008527

CL05A106MP8NUB8

C5008

2203-008527

CL05A106MP8NUB8

C8017,C8018,C8031

2203-008528

CL10A226MPMNUBE

C1060,C1131,C1134

2203-008529

CL05A475MP7NRBC

C1140,C1144,C2038

2203-008529

CL05A475MP7NRBC

C2105,C5000,C5004

2203-008529

CL05A475MP7NRBC

C5005

2203-008529

CL05A475MP7NRBC

C1055,R9019

2203-008691

GRJ033R61A105M

C5041,C5042,C6011

2203-008876

CL03A225MP3CRNC

C6012,C6013,C6014

2203-008876

CL03A225MP3CRNC

C7020

2203-008876

CL03A225MP3CRNC

C5010,C5011,C5012

2203-008885

GRM155R60J226M

C5013,C5064,C5065

2203-008885

GRM155R60J226M

C5066

2203-008885

GRM155R60J226M

TA6000

2404-001561

298D336X06R3M2T

C1003

2703-001726

LL1005-FH27NJ

L1001

2703-001747

LL1005-FH4N7S

L1012

2703-002268

CIH05T8N2JNC

L1091,L1093,L6004

2703-002313

CIH05TR10JNC

L6005

2703-002313

CIH05TR10JNC

L1089,L1092

2703-002596

LQW15AN15NH00D

L1079

2703-002907

LLV0603-F8N2J

L1040,L1041,L1049

2703-002961

MLG0603SR10JT

L1050,L1053,L1096

2703-002961

MLG0603SR10JT

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-10

L2016,L2033,U9008

2703-002961

MLG0603SR10JT

L1078,L2004

2703-002999

CIH03T22NJNC

L1004

2703-003004

LLV0603-F47NJ

L1003

2703-003064

LQG15HSR22J02D

L2013

2703-003545

LQM2MPN2R2NG0

C1126

2703-003686

CIG21L2R2MNE

L1037,L1088,L1090

2703-003755

MIPSZ2012D4R7-SS

L3000,L3001,L3002

2703-003873

LQM2MPN1R5NG0L

L1070

2703-004000

LQP03TN47NJ02D

L7000,L7001

2703-004001

LQP03TN39NJ02D

C1111,C2045,L1016

2703-004012

LQP03TN2N2B02D

L2002

2703-004012

LQP03TN2N2B02D

L1033,L1080,L2001

2703-004018

LQP03TN5N6J02D

C1056,L1009

2703-004030

LQP03TN22NJ02D

L1013,L1077,U9007

2703-004032

LQP03TN3N9B02D

L1014,L1086,L2025

2703-004035

LQP03TN3N3B02D

L2026

2703-004035

LQP03TN3N3B02D

L1027,L1031,L1082

2703-004036

LQP03TN12NJ02D

L1020,L1021,L1029

2703-004037

LQP03TN2N7B02D

L1034,L1075,L2011

2703-004037

LQP03TN2N7B02D

L8000,L8004

2703-004249

PIME061E4R7MS

C2031

2703-004276

CIH05T1N8SNC

L2027

2703-004286

CIH03S3N3BNC

L1005,L2023

2703-004287

CIH03S3N9BNC

L1011,L1064,L1076

2703-004295

AML0603E5N6JT

L1010,L1046

2703-004299

AML0603E1N8BT

R2013

2703-004300

CIH03S1N5BNC

L1062,L1065

2703-004301

CIH03S1N2BNC

L1006,L1069,L1072

2703-004302

AML0603E1N0BT

L1085,L1087

2703-004302

AML0603E1N0BT

L1025,L1026,L1073

2703-004328

LQP03TN4N7H02D

L1030,L1052,L1057

2703-004363

LQP03TG18NJ02D

L1023,L1081,L1083

2703-004366

LQP03TG6N8J02D

L2003

2703-004366

LQP03TG6N8J02D

L1008

2703-004368

LQP03TG15NJ02D

L1007,L1019,L1028

2703-004371

LQP03TG10NJ02D

L1066

2703-004371

LQP03TG10NJ02D

L8005

2703-004543

1239AS-H-100N-P2

C5078

2703-004554

1276AS-H-1R0N-P2

L5000,L5001,L5003

2703-004775

CIGT201610HM1R0SCE

L5004,L5006,L5007

2703-004775

CIGT201610HM1R0SCE

L5009,L5012

2703-004775

CIGT201610HM1R0SCE

L1094,L1095

2703-004853

LQP03TNR12J02D

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-11

L5002,L5005,L5008

2703-004901

CIGT201210UMR47SNE

L5010,L5011

2703-004901

CIGT201210UMR47SNE

OSC2001

2801-005051

FA-128-37.4MHZ

OSC4000

2801-005163

SQBD02400D2JCG

OSC3000

2801-005254

FC-135(12.5PF)

OSC5000

2801-005319

EXS00A-MU00177

OSC2000

2805-001098

KT2016A26000ACW18TAG

OSC1000

2809-001376

KT2520F26000CCW18ZUL

F8000,F8004

2901-001625

ICMEF112P900MFR

F8001,F8002

2901-001647

ICMEF214P101MFR

F7000

2901-001689

ICMEF112P120MFR

C3028,C3029,C4018

2901-001690

NFM15PC435R0G3D

C4019,C4020,C4021

2901-001690

NFM15PC435R0G3D

C4022,C4023,C4024

2901-001690

NFM15PC435R0G3D

C4025,C4026,C4027

2901-001690

NFM15PC435R0G3D

C4028,C4033,C4034

2901-001690

NFM15PC435R0G3D

C4035,C4036,C4037

2901-001690

NFM15PC435R0G3D

C4038,C4054,C4055

2901-001690

NFM15PC435R0G3D

C4056,C4057,C4061

2901-001690

NFM15PC435R0G3D

C4062,C4077,C4078

2901-001690

NFM15PC435R0G3D

C4079

2901-001690

NFM15PC435R0G3D

F8003

2901-001732

ICMEF104P750MFR

F8005,F8006,F8007

2901-001743

ICMED112P900MFR

F8008,F8009

2901-001743

ICMED112P900MFR

F1008

2904-001922

SAFEA2G65FL0F00

L1054

2904-002015

SAFEA806MCM0F00

F1005

2904-002020

SAWEN942MCA0F00

F1006

2904-002091

SFW881YB002

F2003,F2007

2904-002133

ACPF-7124-SG1

F1003

2904-002134

SAFFB2G14AA0F0A

F1007

2904-002145

SAFFB1G84FC0F0A

F2000,F2001

2904-002168

SFHG89GA002

F1004

2904-002190

SAFFB1G84AB0F0A

U1000

2910-000223

B42263EY2045G

F1001

2910-000224

ACMD-6207

F1000

2910-000256

SAYFH806MCA0F3K

U1006

2911-000267

RF7069

U1001

2911-000268

RF7068

F2004,F2008

2911-000294

RFFM8250B

F2006,F2010

2911-000295

RFFM8550B

MIC6000

3003-001215

SPV1840LR5H

L7005,L7006,L9000

3301-001756

BLM15HG102SN1D

L9001,L9002

3301-001756

BLM15HG102SN1D

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-12

L8001

3301-001789

BLM15EG121SN1D

L6000,L6001,L6006

3301-001885

BLM15HD182SN1D

L7002,L7003,L7004

3301-001885

BLM15HD182SN1D

R6016

3301-001885

BLM15HD182SN1D

L1042,L2000,L2029

3301-001895

BLM03AG601SN1D

L1036

3301-001956

BLM21PG220SN1D

U9105

3301-002065

MMZ1005A182ET

L6002,L6003

3301-002078

BLM15AX102SN1D

L1084

3301-002122

BLM15PX121SN1

U9104

3301-002228

BLM15PX330SN1

L8002,L8003

3301-002236

BLM03AX102SN1D

L5013

3301-002269

BLM18FG330SN1D

L9003,L9004

3301-002287

CIC03W601NH

TAC9000,TAC9001

3404-001460

LS12P2E-T

TAC9002

3404-001460

LS12P2E-T

RFS1001

3705-001448

20369-001E

RFS1000

3705-001731

KMS-560-002-BEF

SD7000

3709-001811

SCHA9B0100

SIM7000

3709-001813

SCGH1B0100

HDC6000,HEA7001

3711-007172

AXE610124

HEA9001

3711-007172

AXE610124

HDC6002

3711-007173

AXE612124

HDC8000

3711-007295

AXE634124AW1

HEA4000

3711-007467

AXE620124AW1

HEA7000

3711-007617

14-5804-040-000-829

HDC6001

3711-007810

AXE616124AW1

HEA8001

3711-008163

GB04S-60P-H10-E3000

BTC5000

3711-008421

KN15-6P-1.5V

HEA8000

3711-008511

AXE824124AW1

ANT1000,ANT1001

3712-001490

HJ-1315-NB

ANT1003,ANT1004

3712-001490

HJ-1315-NB

ANT2000,ANT2002

3712-001490

HJ-1315-NB

ANT2003

3712-001490

HJ-1315-NB

ANT9000,ANT9001

3712-001501

HJ-0822-NB

F2005,F2009

4709-002028

LFD182G45DP3B888

U9106

4709-002178

FI168K169706

F8010

4709-002243

LFD181G57DPGC092

FG6001,FG6002

GH61-04949A

SYFB-801114D

CON1000,CON1001

GH62-00029A

SMR-TS-2-1.2-1.25DGR2

CON1002,CON1004

GH62-00029A

SMR-TS-2-1.2-1.25DGR2

CON1006,CON1007

GH62-00029A

SMR-TS-2-1.2-1.25DGR2

CON1008,CON1009

GH62-00029A

SMR-TS-2-1.2-1.25DGR2

CON1010,CON10111

GH62-00029A

SMR-TS-2-1.2-1.25DGR2

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-13

CON10112,CON10113

GH62-00029A

SMR-TS-2-1.2-1.25DGR2

CON10114,CON10115

GH62-00029A

SMR-TS-2-1.2-1.25DGR2

SC1003

GH63-07513A

SHIELDCAN-SMT701-RF03

SUS7002

GH64-03871A

SUS-SMT705-SIM

SUS7001

GH64-03872A

SUS-SMT705-SD

SC1004

GH98-32762A

SHIELDCAN-SMT700-01

SC1006

GH98-32763A

SHIELDCAN-SMT700-02

SC1007

GH98-32764A

SHIELDCAN-SMT700-03

SC1002

GH98-32765A

SHIELDCAN-SMT700-RF01

SC1001

GH98-32766A

SHIELDCAN-SMT700-RF02

SC1005

GH98-32768A

SHIELDCAN-SMT700-AP1

SC1008

GH98-32960A

SHIELDCAN-SMT700-AP2

Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list.

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com
