5. MAIN Electrical Parts List

5-1

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

SEC Code

Design Loc

Description

0401-001110

D500

DIODE-SWITCHING

0406-001413

ZD504

DIODE-TVS

0406-001568

C630,C632,C636,C637

DIODE-TVS

0406-001568

U2104,ZD505,ZD506

DIODE-TVS

0406-001633

ZD400

DIODE-TVS

0406-001642

C495,ZD500,ZD509

DIODE-TVS

0406-001642

ZD510

DIODE-TVS

0406-001645

C565,ZD507,ZD508

DIODE-TVS

0406-001645

ZD511,ZD513,ZD514

DIODE-TVS

0406-001645

ZD515

DIODE-TVS

0406-001648

ZD401,ZD402

DIODE-TVS

0406-001665

D401

DIODE-TVS

0504-001171

TR402

TR-DIGITAL

0601-003477

LED400

LED

0601-003489

LED500,LED501

LED

1001-001928

U502

IC

1108-000578

UME500

IC

1201-003853

U201

IC

1201-003859

PAM1000

IC

1201-003860

PAM1001

IC

1201-003861

PAM1002

IC

1201-003876

U591

IC

1203-006814

U506

IC

1203-007030

U412

IC

1203-007324

U603

IC

1203-007796

U414

IC

1203-008167

U421

IC

1203-008249

U592

IC

1203-008250

U604

IC

1203-008269

U600

IC

1203-008288

U203

IC

1203-008324

U409

IC

1205-004981

U202

IC

1205-005079

U1006

IC

1205-005106

U417

IC

1205-005175

U420

IC

1205-005177

UCP300

IC

1209-002275

U602

IC

1209-002300

U507

IC

1404-001724

TH201,TH300,TH400

THERMISTOR

2007-001306

R410

R-CHIP

2007-007190

R550,R551

R-CHIP

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-2

2007-007315

R303

R-CHIP

2007-007318

R417

R-CHIP

2007-007489

R544

R-CHIP

2007-007589

R202

R-CHIP

2007-007798

R425

R-CHIP

2007-008045

R408,R409,R579

R-CHIP

2007-008055

C596,R414,R532,R536

R-CHIP

2007-008055

R625

R-CHIP

2007-008210

R1001,R324

R-CHIP

2007-008312

R573

R-CHIP

2007-008516

R301,R302,R315,R316

R-CHIP

2007-008516

R336,R341,R342,R343

R-CHIP

2007-008516

R415,R416,R507,R552

R-CHIP

2007-008516

R622,R624

R-CHIP

2007-008531

R609,R611

R-CHIP

2007-008582

R1002,R1003,R574

R-CHIP

2007-008588

R304,R305,R311,R312

R-CHIP

2007-008588

R313,R314,R317,R318

R-CHIP

2007-008588

R590,R591,R607,R608

R-CHIP

2007-008588

R610

R-CHIP

2007-008774

R418,R424

R-CHIP

2007-008788

R323

R-CHIP

2007-008798

R621

R-CHIP

2007-008806

R1004

R-CHIP

2007-008816

R525

R-CHIP

2007-009084

R345,R620

R-CHIP

2007-009155

R504

R-CHIP

2007-009157

R334,R401,R404

R-CHIP

2007-009170

R426

R-CHIP

2007-009223

R526

R-CHIP

2007-009408

R603,R604,R605,R628

R-CHIP

2007-009408

R629

R-CHIP

2007-009793

L532,R527,R528

R-CHIP

2007-009838

C479

R-CHIP

2007-009920

R310,R518,R575

R-CHIP

2007-010856

R413

R-CHIP

2007-011043

R300

R-CHIP

2007-011648

R427

R-CHIP

2203-000233

C549

C-CER, CHIP

2203-000254

C493

C-CER, CHIP

2203-000278

L1002

C-CER, CHIP

2203-000386

C515

C-CER, CHIP

2203-000425

C514

C-CER, CHIP

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-3

2203-005682

C1017,C1027,C1035

C-CER, CHIP

2203-005682

C1037,C1047,C1055

C-CER, CHIP

2203-005682

C1056,C1112,C1119

C-CER, CHIP

2203-005682

C1120,C1121,C1122

C-CER, CHIP

2203-005682

C210,C211,C221,C534

C-CER, CHIP

2203-005682

C560,C561,C624,C640

C-CER, CHIP

2203-005682

L209

C-CER, CHIP

2203-005683

C541

C-CER, CHIP

2203-005725

C1028,C1046,C1116

C-CER, CHIP

2203-005725

C612,L206

C-CER, CHIP

2203-005726

C458,C459

C-CER, CHIP

2203-005729

C540,C547,C548,C562

C-CER, CHIP

2203-005729

C563

C-CER, CHIP

2203-005734

C209,C461

C-CER, CHIP

2203-005736

C109,C1109,C1113

C-CER, CHIP

2203-005736

C207,C212,C216,C224

C-CER, CHIP

2203-005736

C225,L1005,L204,L205

C-CER, CHIP

2203-005789

C1007,L1021

C-CER, CHIP

2203-005792

C1041

C-CER, CHIP

2203-005806

C335,C413,C439

C-CER, CHIP

2203-006048

C1018,C533,C592

C-CER, CHIP

2203-006123

L1044

C-CER, CHIP

2203-006194

C375,C379

C-CER, CHIP

2203-006379

C323,C350,C353

C-CER, CHIP

2203-006399

C238,C477,C505

C-CER, CHIP

2203-006401

C538,C539

C-CER, CHIP

2203-006423

C1077,C1078,C1079

C-CER, CHIP

2203-006423

C1082,C1083,C1084

C-CER, CHIP

2203-006423

C1085,C1089,C1090

C-CER, CHIP

2203-006423

C1099,C1105,C219

C-CER, CHIP

2203-006423

C300,C303,C305,C306

C-CER, CHIP

2203-006423

C311,C312,C313,C314

C-CER, CHIP

2203-006423

C315,C316,C318,C319

C-CER, CHIP

2203-006423

C320,C322,C341,C342

C-CER, CHIP

2203-006423

C343,C344,C345,C346

C-CER, CHIP

2203-006423

C365,C366,C367,C368

C-CER, CHIP

2203-006423

C380,C381,C388,C389

C-CER, CHIP

2203-006423

C400,C435,C438,C456

C-CER, CHIP

2203-006423

C502,C522,C523,C528

C-CER, CHIP

2203-006423

C530,C557,C558,C628

C-CER, CHIP

2203-006556

C535

C-CER, CHIP

2203-006562

C440,C441,C490,C492

C-CER, CHIP

2203-006562

C650

C-CER, CHIP

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-4

2203-006647

C354,C378

C-CER, CHIP

2203-006648

C229,C339

C-CER, CHIP

2203-006665

L1032

C-CER, CHIP

2203-006668

C336,C347,C376

C-CER, CHIP

2203-006815

C352,C374,C460

C-CER, CHIP

2203-006838

C478,C511

C-CER, CHIP

2203-006839

C1049,C1114,C237

C-CER, CHIP

2203-006839

C414,C500,C513,C622

C-CER, CHIP

2203-006839

C635

C-CER, CHIP

2203-006872

C410

C-CER, CHIP

2203-006896

C564

C-CER, CHIP

2203-006978

C487,C488

C-CER, CHIP

2203-006979

C471

C-CER, CHIP

2203-006994

C348,C351,C373

C-CER, CHIP

2203-007133

BAT400

C-CER, CHIP

2203-007165

C204

C-CER, CHIP

2203-007194

C220

C-CER, CHIP

2203-007240

C382,C383,C450,C451

C-CER, CHIP

2203-007271

C1026,C402,C406,C407

C-CER, CHIP

2203-007271

C472

C-CER, CHIP

2203-007317

C1070,C418,C419,C420

C-CER, CHIP

2203-007317

C529,C531,C639

C-CER, CHIP

2203-007369

C629

C-CER, CHIP

2203-007391

C205,C232

C-CER, CHIP

2203-007392

C1001,C1044

C-CER, CHIP

2203-007393

C1019,C1068,C239

C-CER, CHIP

2203-007393

C462,C467,C607

C-CER, CHIP

2203-007449

C1088,C317,C321,C324

C-CER, CHIP

2203-007449

C325,C326,C327,C328

C-CER, CHIP

2203-007449

C349,C369,C370,C371

C-CER, CHIP

2203-007449

C372,C377,C384,C385

C-CER, CHIP

2203-007449

C386,C387,C390,C391

C-CER, CHIP

2203-007449

C403,C416,C417,C429

C-CER, CHIP

2203-007449

C430,C434,C436,C437

C-CER, CHIP

2203-007449

C457,C464,C484,C486

C-CER, CHIP

2203-007449

C516,C532,C566,C601

C-CER, CHIP

2203-007449

C603,C606,C608,C609

C-CER, CHIP

2203-007449

C613,C615,C631,C634

C-CER, CHIP

2203-007449

C645,C646

C-CER, CHIP

2203-007775

C422,C489

C-CER, CHIP

2203-007781

C590

C-CER, CHIP

2203-007795

C1020,C201,C203,C206

C-CER, CHIP

2203-007795

C240,C474,C480,C591

C-CER, CHIP

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-5

2203-007795

C616,C617,C618,C619

C-CER, CHIP

2203-007795

C620

C-CER, CHIP

2203-007796

C463,C468,C469,C476

C-CER, CHIP

2203-007796

C483,C567,C595,C597

C-CER, CHIP

2203-007796

C602,C604,C623

C-CER, CHIP

2203-008094

C470

C-CER, CHIP

2203-008097

C550,C559

C-CER, CHIP

2203-008242

C501,C504,C510,C610

C-CER, CHIP

2203-008242

C614

C-CER, CHIP

2203-008243

C223,C226,C227,C228

C-CER, CHIP

2203-008394

C605

C-CER, CHIP

2203-008470

C304,C641,C642

C-CER, CHIP

2203-008654

C475

C-CER, CHIP

2203-008749

C611

C-CER, CHIP

2203-008876

C408,C409,C412,C556

C-CER, CHIP

2203-009328

C404,C405,C448,C449

C-CER, CHIP

2203-009328

C452,C453,C454,C455

C-CER, CHIP

2203-009328

C485

C-CER, CHIP

2703-002267

C1002

INDUCTOR-SMD

2703-002649

C1029,L1028

INDUCTOR-SMD

2703-002901

C1054

INDUCTOR-SMD

2703-002903

L1029,L1041

INDUCTOR-SMD

2703-002907

L1026

INDUCTOR-SMD

2703-002919

L202

INDUCTOR-SMD

2703-002958

L207,L212

INDUCTOR-SMD

2703-002959

L516

INDUCTOR-SMD

2703-003121

U2001

INDUCTOR-SMD

2703-003686

L300

INDUCTOR-SMD

2703-003755

L411

INDUCTOR-SMD

2703-003878

L528

INDUCTOR-SMD

2703-004000

L104

INDUCTOR-SMD

2703-004012

L1000,L1001

INDUCTOR-SMD

2703-004013

L1007,L1008

INDUCTOR-SMD

2703-004018

C1115,L1015,U1013

INDUCTOR-SMD

2703-004030

C1000

INDUCTOR-SMD

2703-004032

L1006

INDUCTOR-SMD

2703-004034

C222,L1013

INDUCTOR-SMD

2703-004035

C1016,L1003,L1024

INDUCTOR-SMD

2703-004035

L1025

INDUCTOR-SMD

2703-004036

L1018

INDUCTOR-SMD

2703-004299

C234

INDUCTOR-SMD

2703-004328

L208,L211

INDUCTOR-SMD

2703-004338

C421

INDUCTOR-SMD

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-6

2703-004366

L210

INDUCTOR-SMD

2703-004367

C218

INDUCTOR-SMD

2703-004368

L1031

INDUCTOR-SMD

2703-004775

L590

INDUCTOR-SMD

2703-004976

L1011,L1012

INDUCTOR-SMD

2703-005017

L216

INDUCTOR-SMD

2703-005061

L402,L403

INDUCTOR-SMD

2703-005102

L400,L410

INDUCTOR-SMD

2703-005108

L602

INDUCTOR-SMD

2703-005109

L401

INDUCTOR-SMD

2703-005159

L603

INDUCTOR-SMD

2801-005390

OSC400

CRYSTAL-SMD

2901-001635

F605,F607,F608,F609

FILTER

2901-001635

F610

FILTER

2901-001673

F603

FILTER

2901-001674

F604,F606

FILTER

2904-002136

F1001

FILTER

2904-002168

F201

FILTER

2909-001386

F202

FILTER

2910-000214

F1000

DUPLEXER

2910-000320

F1002

DUPLEXER

2910-000321

F1004

DUPLEXER

2910-000337

F1003

DUPLEXER

3003-001208

MIC500

MIC MEMS

3301-001534

L201

BEAD-SMD

3301-001729

L500

BEAD-SMD

3301-001885

L501,L509,L510,L529

BEAD-SMD

3301-001885

L530

BEAD-SMD

3301-001901

L606

BEAD-SMD

3301-001914

L408

BEAD-SMD

3301-002062

L507,L508

BEAD-SMD

3301-002078

R576,R577

BEAD-SMD

3301-002179

L214,L215

BEAD-SMD

3301-002228

L1010

BEAD-SMD

3301-002236

L412,L414,L415,L502

BEAD-SMD

3301-002236

L517,L531,R530

BEAD-SMD

3301-002243

L601,L604,L605

BEAD-SMD

3301-002248

L203

BEAD-SMD

3301-002254

L413

BEAD-SMD

3301-002286

L527

BEAD-SMD

3404-001487

TAC500,TAC501,TAC502

SWITCH-TACT

3705-001708

RFS1000

CONNECTOR-COAXIAL

3709-001799

SIM600

CONNECTOR-CARD EDGE

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-7

3709-001863

SIM601

CONNECTOR-CARD EDGE

3711-007295

HDC601

HEADER-BOARD TO BOARD

3711-007478

HDC500

HEADER-BOARD TO BOARD

3711-007883

HDC600

HEADER-BOARD TO BOARD

3711-008511

HDC602

HEADER-BOARD TO BOARD

3711-008737

BTC400

CONNECTOR-BATTERY

3712-001516

ANT1000,ANT201

CONNECTOR-TERMINAL

3712-001516

ANT202,ANT500,ANT501

CONNECTOR-TERMINAL

3712-001516

ANT502,ANT503,ANT504

CONNECTOR-TERMINAL

3712-001516

ANT505

CONNECTOR-TERMINAL

3722-003708

IFC400

JACK-MICRO USB

GH61-08265A

SUS1001,SUS1002

PLATE-SMD A

GH61-08265A

SUS1003

PLATE-SMD A

GH61-08266A

SUS1000

PLATE-SMD B

GH63-09456A

SC1002

SHIELD-FRAME D

GH63-09457A

SC1002

SHIELD-COVER E

GH80-03321A

R1000,R631

SOLDER-CREAM G

GH98-35507A

SC1004

ASSY SHIELD CAN-SMDB

GH98-35508A

SC1003

ASSY SHIELD CAN-SMDC

GH98-36047A

SC1001

ASSY SHIELD CAN-F

Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list.

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com
