5. MAIN Electrical Parts List

5-1

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Design LOC

SEC CODE

Description

D401

0401-001110

DIODE-SWITCHING

ZD507,ZD511,ZD512

0406-001223

DIODE-TVS

ZD514,ZD515

0406-001223

DIODE-TVS

ZD500,ZD502

0406-001459

DIODE-TVS

D402

0406-001633

DIODE-TVS

ZD403,ZD510,ZD513

0406-001649

DIODE-TVS

D400

0406-001665

DIODE-TVS

ZD505,ZD506

0406-001678

DIODE-TVS

ZD401,ZD402

0406-001690

DIODE-TVS

ZD508,ZD509

0406-001695

DIODE-TVS

LED400

0601-003483

LED

U500

1001-001928

IC

UME300

1108-000584

MEMORY

PAM101

1201-003581

IC

U200

1201-003790

IC

U100

1201-003856

IC

PAM100

1201-003890

IC

U600

1203-008149

IC

U400

1203-008416

IC

U401

1203-008565

IC

U103

1205-005067

IC

U402

1205-005106

IC

U203

1205-005134

IC

U403

1205-005175

IC

UCP300

1205-005183

IC

U202

1205-005220

IC

U602

1209-002275

IC

TH100,TH400,TH401

1404-001694

THERMISTOR

R504,R515

2007-000140

R-CHIP

R601

2007-000141

R-CHIP

R318

2007-000148

R-CHIP

R422

2007-000162

R-CHIP

R429

2007-000169

R-CHIP

R509

2007-000831

R-CHIP

R508

2007-007014

R-CHIP

R106

2007-007107

R-CHIP

R432

2007-007156

R-CHIP

R405,R406,R605

2007-007190

R-CHIP

R319

2007-007517

R-CHIP

R105

2007-007538

R-CHIP

R314,R317

2007-007741

R-CHIP

R401,R402

2007-007861

R-CHIP

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-2

R107

2007-008043

R-CHIP

R420,R503

2007-008045

R-CHIP

R204,R516,R517,R527

2007-008055

R-CHIP

R606

2007-008055

R-CHIP

R411,R412,R413,R414

2007-008419

R-CHIP

R417,R427,R511,R512

2007-008419

R-CHIP

R604

2007-008419

R-CHIP

R102,R408,R409

2007-008478

R-CHIP

R525,R526,R528,R529

2007-008483

R-CHIP

R530

2007-008483

R-CHIP

R308,R309,R326,R337

2007-008516

R-CHIP

R340,R342,R510,R513

2007-008516

R-CHIP

R415,R428,R531,R610

2007-008531

R-CHIP

R418,R419,R500,R505

2007-008587

R-CHIP

R514

2007-008587

R-CHIP

R320,R321,R322,R323

2007-008588

R-CHIP

R324,R325,R328,R329

2007-008588

R-CHIP

R410

2007-008648

R-CHIP

R430,R431

2007-008774

R-CHIP

R310

2007-008788

R-CHIP

R101

2007-008806

R-CHIP

R201

2007-009111

R-CHIP

R423

2007-009170

R-CHIP

R522

2007-009212

R-CHIP

R407

2007-009766

R-CHIP

R108,R109

2007-009801

R-CHIP

R425

2007-009838

R-CHIP

R339

2007-009920

R-CHIP

R523

2007-009969

R-CHIP

R403,R404

2007-010202

R-CHIP

R313,R315,R330

2007-010233

R-CHIP

R426

2007-010848

R-CHIP

R331

2007-011043

R-CHIP

C148,C150,C152

2203-000278

C-CERAMIC,CHIP

C477,C482,C606

2203-000854

C-CERAMIC,CHIP

C485

2203-001153

C-CERAMIC,CHIP

C429,C618,C619

2203-002709

C-CERAMIC,CHIP

C604

2203-005249

C-CERAMIC,CHIP

C202,C204,C235

2203-005682

C-CERAMIC,CHIP

C230

2203-005725

C-CERAMIC,CHIP

C600

2203-005726

C-CERAMIC,CHIP

C500,C522

2203-005729

C-CERAMIC,CHIP

C529

2203-005731

C-CERAMIC,CHIP

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-3

C475,C509,C523,C525

2203-005732

C-CERAMIC,CHIP

C527,C532

2203-005732

C-CERAMIC,CHIP

L134

2203-005734

C-CERAMIC,CHIP

C117,C139,C201,C203

2203-005736

C-CERAMIC,CHIP

C205,R200

2203-005736

C-CERAMIC,CHIP

C234

2203-005777

C-CERAMIC,CHIP

C167,L102

2203-005789

C-CERAMIC,CHIP

C449,C535,C603,C611

2203-006048

C-CERAMIC,CHIP

C132

2203-006121

C-CERAMIC,CHIP

C448

2203-006137

C-CERAMIC,CHIP

C206

2203-006190

C-CERAMIC,CHIP

C321,C330,C351,C352

2203-006194

C-CERAMIC,CHIP

C158,C208,C232,C236

2203-006305

C-CERAMIC,CHIP

C237,C404,C406

2203-006305

C-CERAMIC,CHIP

R100

2203-006318

C-CERAMIC,CHIP

C451,C468,C469

2203-006379

C-CERAMIC,CHIP

C207,C212,C216,C218

2203-006399

C-CERAMIC,CHIP

C219,C223,C224,C227

2203-006399

C-CERAMIC,CHIP

C228,C320,C413,C418

2203-006399

C-CERAMIC,CHIP

C420,C440

2203-006399

C-CERAMIC,CHIP

C162,C164,C222,C536

2203-006400

C-CERAMIC,CHIP

C537

2203-006400

C-CERAMIC,CHIP

C511

2203-006401

C-CERAMIC,CHIP

C154,C156,C306,C307

2203-006423

C-CERAMIC,CHIP

C308,C325,C327,C328

2203-006423

C-CERAMIC,CHIP

C528,C530

2203-006423

C-CERAMIC,CHIP

C200

2203-006462

C-CERAMIC,CHIP

C106,C111,C112,C115

2203-006556

C-CERAMIC,CHIP

C122,C124,C131,C135

2203-006556

C-CERAMIC,CHIP

C136,C138,C145,C146

2203-006556

C-CERAMIC,CHIP

C147,C161,C226,C455

2203-006556

C-CERAMIC,CHIP

C456

2203-006556

C-CERAMIC,CHIP

C101,C109,C474

2203-006562

C-CERAMIC,CHIP

C159

2203-006665

C-CERAMIC,CHIP

C453

2203-006668

C-CERAMIC,CHIP

C305,C315,C318,C332

2203-006681

C-CERAMIC,CHIP

C100,C121,C130,C165

2203-006707

C-CERAMIC,CHIP

C166

2203-006707

C-CERAMIC,CHIP

C507,C508

2203-006815

C-CERAMIC,CHIP

C331

2203-006824

C-CERAMIC,CHIP

C116,C424,C436,C480

2203-006839

C-CERAMIC,CHIP

C503,C504

2203-006839

C-CERAMIC,CHIP

C213,C437

2203-006872

C-CERAMIC,CHIP

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-4

L204

2203-006896

C-CERAMIC,CHIP

C231,C506

2203-006979

C-CERAMIC,CHIP

C316,C322,C461,C464

2203-007240

C-CERAMIC,CHIP

C466,C467

2203-007240

C-CERAMIC,CHIP

C462,C463,C465

2203-007270

C-CERAMIC,CHIP

C229,C304,C310,C313

2203-007271

C-CERAMIC,CHIP

C314,C323,C479

2203-007271

C-CERAMIC,CHIP

C317,C319,C324

2203-007279

C-CERAMIC,CHIP

C102,C113,C118,C119

2203-007317

C-CERAMIC,CHIP

C214,C402

2203-007317

C-CERAMIC,CHIP

C612,C613

2203-007369

C-CERAMIC,CHIP

C221,C300,C301,C432

2203-007393

C-CERAMIC,CHIP

C444,C446,C478,C483

2203-007393

C-CERAMIC,CHIP

C524,C614,C615,C616

2203-007393

C-CERAMIC,CHIP

C149,C151,C153,C157

2203-007449

C-CERAMIC,CHIP

C311,C329,C334,C335

2203-007449

C-CERAMIC,CHIP

C343,C345,C346,C347

2203-007449

C-CERAMIC,CHIP

C457,C458,C459,C470

2203-007449

C-CERAMIC,CHIP

C326

2203-007474

C-CERAMIC,CHIP

C484,C605

2203-007634

C-CERAMIC,CHIP

C211,C217

2203-007775

C-CERAMIC,CHIP

C400,C401,C423,C430

2203-007795

C-CERAMIC,CHIP

C433,C442,C445,C454

2203-007795

C-CERAMIC,CHIP

C512,C602,C607,C617

2203-007795

C-CERAMIC,CHIP

C209,C210,C225,C408

2203-007796

C-CERAMIC,CHIP

C410,C414,C415,C428

2203-007796

C-CERAMIC,CHIP

C447,C452,C473,C510

2203-007796

C-CERAMIC,CHIP

C513,C517,C521,C609

2203-007796

C-CERAMIC,CHIP

C610

2203-007796

C-CERAMIC,CHIP

C220,C302,C303,C309

2203-008097

C-CERAMIC,CHIP

C312,C333,C336,C337

2203-008097

C-CERAMIC,CHIP

C338,C339,C340,C341

2203-008097

C-CERAMIC,CHIP

C342

2203-008097

C-CERAMIC,CHIP

C155,C349,C407,C409

2203-008242

C-CERAMIC,CHIP

C412,C416,C417,C419

2203-008242

C-CERAMIC,CHIP

C421,C422,C427,C434

2203-008242

C-CERAMIC,CHIP

C435,C486,C608

2203-008242

C-CERAMIC,CHIP

C344

2203-008243

C-CERAMIC,CHIP

C620

2203-008394

C-CERAMIC,CHIP

C472

2203-008654

C-CERAMIC,CHIP

C405

2203-008790

C-CERAMIC,CHIP

C441,C443,C460,C471

2203-008876

C-CERAMIC,CHIP

C481

2203-008876

C-CERAMIC,CHIP

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-5

C425,C431,C438,C439

2203-009328

C-CERAMIC,CHIP

L101

2703-002170

INDUCTOR-SMD

L505

2703-002313

INDUCTOR-SMD

L213

2703-002314

INDUCTOR-SMD

L210

2703-002365

INDUCTOR-SMD

L104,L112

2703-002958

INDUCTOR-SMD

L203

2703-003004

INDUCTOR-SMD

L506

2703-003878

INDUCTOR-SMD

L127

2703-004018

INDUCTOR-SMD

L121

2703-004032

INDUCTOR-SMD

L117,L118,L120

2703-004034

INDUCTOR-SMD

C104,L132

2703-004035

INDUCTOR-SMD

L125,L129

2703-004036

INDUCTOR-SMD

L133

2703-004288

INDUCTOR-SMD

L135

2703-004289

INDUCTOR-SMD

L100,L106

2703-004295

INDUCTOR-SMD

L408,L409

2703-004298

INDUCTOR-SMD

L122,L124

2703-004301

INDUCTOR-SMD

L402,L405,L406

2703-004318

INDUCTOR-SMD

L119,L123,L211,L212

2703-004328

INDUCTOR-SMD

L201

2703-004362

INDUCTOR-SMD

L111,L116

2703-004363

INDUCTOR-SMD

L130,L209

2703-004366

INDUCTOR-SMD

L113,L202

2703-004367

INDUCTOR-SMD

L108

2703-004371

INDUCTOR-SMD

L400,L401,L403,L404

2703-004599

INDUCTOR-SMD

L206

2703-004914

INDUCTOR-SMD

L602

2703-005007

INDUCTOR-SMD

OSC400

2801-004820

CRYSTAL-UNIT

OSC100

2801-005144

CRYSTAL-UNIT

OSC200

2805-001113

OSCILLATOR

F101

2904-002111

FILTER-SAW

F200,F201

2904-002132

FILTER-SAW

U102

2904-002247

FILTER-SAW

F202

2909-001307

FILTER-DUPLEXER

F104

2910-000295

FILTER

F103

2910-000314

FILTER

MIC500

3003-001207

MIC-CONDENSOR

L207

3301-001438

CORE-FERRITE BEAD

L603,U601

3301-001534

CORE-FERRITE BEAD

L512,L515

3301-001787

CORE-FERRITE BEAD

L600

3301-001876

CORE-FERRITE BEAD

L501,L502,L503

3301-001885

CORE-FERRITE BEAD

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com

background image

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-6

L205,L208

3301-001895

CORE-FERRITE BEAD

L500,L507,L508

3301-001917

CORE-FERRITE BEAD

L601

3301-002063

CORE-FERRITE BEAD

L105

3301-002228

CORE-FERRITE BEAD

L511,L514

3301-002237

CORE-FERRITE BEAD

L200

3301-002238

CORE-FERRITE BEAD

L504,U501

3301-002242

CORE-FERRITE BEAD

L407

3301-002254

CORE-FERRITE BEAD

L510,L513

3301-002286

CORE-FERRITE BEAD

L509

3301-002287

CORE-FERRITE BEAD

CN500

3404-001508

SWITCH-TACT

TAC500,TAC501,TAC502

3404-001540

SWITCH-TACT

CON100

3705-001708

CONNECTOR-COAXIAL

CD500

3709-001786

CONNECTOR-CARD EDGE

SIM500,SIM501

3709-001830

CONNECTOR-CARD EDGE

SOC600

3710-003306

CONNECTOR-SOCKET

HDC600

3711-007107

CONNECTOR-HEADER

HDC601

3711-007467

CONNECTOR-HEADER

BTC400

3711-008776

CONNECTOR-HEADER

ANT501,ANT502

3712-001516

CONNECTOR

ANT100,ANT101

3712-001517

CONNECTOR

ANT400,ANT401

3712-001528

CONNECTOR

ANT200,ANT201

3712-001547

CONNECTOR

IFC400

3722-003678

JACK-PHONE

EAR500

3722-003731

JACK-PHONE

P l e a s e c o n s u l t t h e G S P N w e b s i t e ( S a m s u n g P o r t a l ) f o r t h e m o s t r e c e n t v e r s i o n o f t h e p r o d u c t ' s p a r t l i s t .

http://www.easy-firmware.com

EASY

F

IRMWARE

EASY

FIRMWARE

www.easy-firmware.com


Wyszukiwarka

Podobne podstrony:
SM G360FY EPLIS 11
SM J700F EPLIS 11
SM P901 EPLIS 11
SM G350E EPLIS 11
SM A300H EPLIS 11
SM G7202 EPLIS 11
SM G600FY EPLIS 11
SM G900F EPLIS 11
SM A710FD EPLIS 11
SM T805 EPLIS 11
SM G920F EPLIS 11
SM T531 EPLIS 11
SM N900 EPLIS 11
SM J500F EPLIS 11
SM G920F EPLIS 11
SM G531H EPLIS 11
SM T705 EPLIS 11

więcej podobnych podstron
