Data Sheet

FUJITSU Mainboard Accessories

Page 1 of 3

ts.fujitsu.com/mainboards

Data Sheet

Fujitsu Mainboard Accessories

Passive Mini-ITX Heatsink AMD for Industrial Mainboards
D3003-S1 / D3313-S1

Passive Heatsink Kit for Mini-ITX mainboards – designed for fanless chassis solutions for

AMD embedded G-Series APU (D3003-S1) and embedded G-Series SoC (D3313-S1)

Heatsink F5000-C006:

Full aluminium
Spring-loaded mounting screws for specified downforce
Recommended mounting screw torque = 0.6Nm

Order Code:

S26361-F5000-C006 (backplate included)
(previous order code: V26898-B972-V1)

Backplate:

Metal backplate, provides 4 mounting threads for heatsink

Supported processors:

D3003-S1: AMD T44R APU (1.2GHz SingleCore / 9W)
D3313-S1: AMD GX-210HA SOC (1GHz DualCore / 9W)





















(insulating foil resp. insulating plate)

V26898-B883-V100 (alternative backplates) V26898-B883-V10


Important Note:

Insulating foil of backplate –B883-V100 must NOT be removed,

otherwise mainboard may be damaged due to possible

shortcut.


Dimensions:

background image

Data Sheet

FUJITSU Mainboard Accessories

Page 2 of 3

ts.fujitsu.com/mainboards



















Further industrial products offered by Fujitsu

Connectors

KVM Switches

Relays

Touch Panels

Thermal Printers

Wireless Modules

24 Volt Kiosk Printers Multi-Input Touch Panels
















Contact:

Fujitsu Components Europe, B.V.
Tel.: +31 (0)23 556 0910
Fax: +31 (0)23 556

0950

Website: emea.fujitsu.com/components

Address: Diamantlaan 25
2132 WV Hoofddorp
Netherlands
