DS F5000 C003 HS D2963 Active

background image

Data Sheet

Fujitsu Mainboard Accessories

Page 1 of 2

ts.fujitsu.com/mainboards

Data Sheet

Fujitsu Mainboard Accessories

Mini-ITX Heatsink for Mainboard D2963-S

Active heatsink for mini-ITX mainboard D2963-S – designed for silent cooling

Heatsink F5000-C003:

Full aluminum incl. metal backplate
Spring-loaded mounting screws for specified downforce

Order Code:

S26361-F5000-C003 (backplate included)

(previous order code: C26361-D6000-C200 / V26898-B883-V100)

Integrated fan:

Fan 60 mm, ball bearing
4 pin PWM Connector
Speed: max. 6.000 rpm
Sound level: 20 dB(A) - 42dB(A) max.
MTBF: ~ 40.000hrs

Supported processors:

All AMD embedded G-Series processors

Dimensions:

















(insulating foil)



Important Note:

Insulating foil of backplate must NOT be removed,

otherwise mainboard may be damaged due to possible

shortcut.
