INK

Computing in Real Time

people will agree that when developing

code for an embedded controller, there is usually

some degree of “real-time programming” involved. It’s

that ever so tenuous balance between code complexity,

code size,

execution speed,

and response time. Programs running on a

desk-top machine can handle unrelated tasks in any order and can take their
time doing so. Speed comes into play only when testing the user’s patience.

However, when the tables are turned and the microprocessor must

respond in a timely manner to any number of asynchronous external stimuli,

code complexity increases rapidly unless the programmer uses different
techniques when wriiing the code. Enter multitasking.

Multitasking kernels generally come in two flavors: preemptive and

nonpreemptive. In our first article, past design contest winner Mike
Podanoffsky shows how a simple preemptive multitasking kernel

be

written in C. In a nonpreemptive system (like Microsoft Windows), tasks can’t
be interrupted, so they must cooperate with each other to get useful work
done. In our second article, Robert Scott goes on lo describe some
techniques for making sometimes selfish tasks play nice together.

Related to real-time control is a special kind of microcontroller: the

PLC, or programmable

controller. Francis Lyn walks us through some

of the history behind

and gives examples of one system available

today.

Now that you’ve collected a large amount of data with your embedded

controller, what better way to save some space than to compress that data?
You’ve probably heard the names Lempel, Ziv, and Welch (what ever
happened to Smith and Jones?); now you can find out what they did for
compression algorithms. Dwayne Philips describes how the LZW compres-
sion method

and illustrates the algorithm with some working code.

Enough with the software. Let’s get down to the chip level again with a

comparison of two data logger designs: one using an

and the other a

Dallas Semicondudor

John Dybowski covers all the bases,

detailing how he made his component choices in the two designs.

In our columns, Ed wvers yet another HCS II module: the LCD-Link.

Now the HCS has a way to

with humans on the fly. Jeff digs up an

old Circuit Cellar article and explores the use of simulators in checking the
characteristics of a design. Tom pulls out another industry

multimedia--and looks at what’s happening in the arena with his usual
skepticism. Finally, John Dybowski (hmm, that name keeps popping up)
describes how to make your embedded system more bulletproof through the
proper use of watchdog timers.
