background image

Exploded View and Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

4-2

Design LOC

Description

SEC CODE

QCR12

SCREW-MACHINE

6001-001530

QCR67

SCREW-MACHINE

6001-002083

QCR97

SCREW-MACHINE

6001-002262

QMO01

MOTOR LINEAR VIBRATION-LINEAR MOTOT FPCB

GH31-00585A

QCA02

CAMERA MODULE-1.9M VT 1/6 LSI(GT-I9300)

GH59-12097A

QSP01

MODULE-GT_I9300 SPK+INTENNA+EARJACK

GH59-12159A

QAN04

MODULE-GT_I9300 ANT SUB PCB

GH59-12196A

QAR01

MODULE-GT_I9300 RCV+LED+V/K

GH59-12217A

QVO01

KEY-VOLUME

GH64-00403A

QCK01

KEY-POWER_V2

GH64-00489A

QMP01

A/S ASSY-PBA MAIN(COMM)GT_I9300

GH82-06521A

QCA01

ASSY CAMERA-8M 1/3.2 LSI(GT_I9300)

GH96-05593A

QME02

ASSY MODULE-GT_I9300 SUB PBA+BRACKET

GH96-05609A

QBC00

ASSY COVER-BATT

GH98-23340A

QRE01

ASSY CASE-REAR

GH98-23341A

4-2. Cellular phone Parts list
