2 of 2

4 / 3 / 2 Channel Power Amplifier

3555

3555

111-01

Red (Right)

White (Left)

Low Level

Output

Remote - Out

or

Power Antenna Lead

Red (Right)

White (Left)

Front (Low Level)

Rear (Low Level)

Remote-On Lead
(Blue/White - +12V
Input turns Amp on)

Ground Lead (Black)

Battery Lead (Yellow)

Battery

+

-

Fuse Holder (60A)

Battery Power

Wire (Optional)

Front Left Speaker Output Lead (-)

Front Left Speaker Output Lead (+)

Front Right Speaker Output Lead (+)

Front Right Speaker Output Lead (-)

Rear Left Speaker Output Lead (-)

Rear Left Speaker Output Lead (+)

Rear Right Speaker Output Lead (+)

Rear Right Speaker Output Lead (-)

Front Left Speaker Output Lead (+)

Front Right Speaker Output Lead (-)

Rear Left Speaker Output Lead (+)

Rear Right Speaker Output Lead (-)

4 Ohm Mono Loading ONLY

2 Ohm or 4 Ohm Stereo Loading

This Amplifier is Capable of running MultiMode™

4 Ohm Mono Loading ONLY

2 Ohm or 4 Ohm Stereo Loading

20A

1

CH

2

CH

3

CH

4

CH

INPUT

20A

20A

BATT

REMOTE

GND

MADE IN JAPAN

+

-

+

-

+

-

BRIDGED

BATT REMOTE

GND

MADE IN JAPAN

4

CH

3

CH

2

CH

1

CH

+

-

BRIDGED

+

-

LEFT

RIGHT

LEFT (MONO)

1

CH

2

CH

3

CH

4

CH

INPUT

RIGHT LEFT (MONO)

+

-

RIGHT

+

-

BRIDGED

+

-

LEFT

+

-

RIGHT

+

-

RIGHT

+

-

LEFT

+

-

RIGHT

+

-

LEFT

+

-

BRIDGED

Wire

Assembly

Part No.

01E08346S01

Wire

Assembly

Part No.

01E06306S01

(includes both)
