Cessna 172XP Small Checklist

background image

Landing Pattern

19" 2100

95

15" Full

90 F10

13" Full

80 F20

11" Full

70 F30

Speeds

KIAS

Vso

46

Vs1

54

Vr

55

Vx

60

Vy

73

Vg

75

Vfe

85 / 110

Va (gross wt.)

105

Vno

129

Vne

163

Demo Xwind

20

Short TO

60 F10

Short TO w / Obs 60 F10
Soft TO

F15

Soft TO w / Obs

F10

Enroute Climb

85 - 95

App Short

63 F40

App Flaps Down

70 - 60

App Flaps Up

75 - 65

Vcruise @75%

120

Capacities
Full - Min Oil

9 - 6 qts.

Fuel

52

Usable Fuel

49

75% Cruise

12.0 GPH

Useful Load

911 lbs.

NOSE

Oil Quantity………….…. CHECK
Main Fuel Strainer……….DRAIN
Air Inlet……...……….… CLEAR
Propeller.…CHECK CONDITION
Spinner…...CHECK CONDITION
Alternator Belt…………SECURE
Cowling Air Inlets…….… CLEAR
Nose Tire, Strut………... CHECK
Cowl Flap..………….… SECURE
Windshield……………… CLEAN
Static Port………………. CLEAR

LEFT WING

Same Checks As Right Wing
Pitot Tube…….…….….. CLEAR
Fuel Vent………………..CLEAR
Stall Warning………….. CHECK

GENERAL CONDITION

Condition Of Aircraft…. .CHECK
Performance.........…COMPUTE
Tiedowns............... RELEASED
Static wicks................. CHECK

For reference only - check official information

INTERIOR

Aircraft Documents……. AROW
Control Lock…………. REMOVE
Master Switch………………. ON
Fuel Qty Indications..... CHECK
All Lights……………….. CHECK
Flaps……………………EXTEND
Pitot Heat (if IFR)......... CHECK
Master Switch…………….. OFF
Ignition Switch……………..OFF
Cowling……………..…SECURE

EXTERIOR -

EMPENNAGE

Radio Antennas………SECURE
Windows……………… CLEAR
Baggage Door..…..…..SECURE
Horizontal Stab…………CHECK
Elevator…...FREE MOVEMENT
Vertical Stab……………CHECK
Rudder….…FREE MOVEMENT
Control Cables……….…CHECK
Trim Tab……………….SECURE
Hinges…………… CHECK ELT
Cover Plate……… SECURE

RIGHT WING

Right Fuel Sump………...DRAIN
Right Flap………………. CHECK
Right Aileron……………. CHECK
Wing…... FREE OF ICE, FROST
Fuel Tank/ Qty/ Cap….. CHECK
Air Inlet…………………. CLEAR
Right Main Wheel……. INSPECT
Brake Assembly……….. CHECK

FANNING FIELD INFO

Elevation…………………4744 ft.

Traffic Pattern Altitude… 5700 ft

Tower Freq…..…………. 118.50

Ground Control………….121.70

AeroMark (Fuel)…………122.95

ASOS…………………… 133.325

208-524-4553

Salt Lake Approach……..128.35

FSS - BOISE…… 122.55, 122.2

.
