This paper describes DriveLoaderModule.INI, which can be used to configure the system
software restoring process of the DriveLoader module version 2.21 or newer.

2. General

DriveLoader module version 2.21 is included in DriveWindow 2 version 2.21.

The configurable new version of the module is compatible with older versions. Thus older
DriveWindow 2 installations can be upgraded to use the new configurable version.

DriveLoaderModule.INI structure follows the industry standard. Thus it is an ASCII-file consisting
of sections that contain key-value pairs. The file should reside in the Windows folder.

If no DriveLoaderModule.INI exists (or it is empty), the configurable DriveLoader module behaves
exactly as older versions, i.e., the new drive operating system is not loaded into RAM of the drive
before restoring unless absolutely necessary.

By using the DriveLoaderModule.INI-file during the system software restoring process
DriveLoader module determines, whether to load the new drive operating system to drive RAM or
not, even if it is not absolutely necessary. It is also possible to deny restoring of some
combinations of system software versions in a drive and in a backup package.

The new DriveLoader module uses contents of SW_PACK*.TXT files both in the drive and in the
backup package to determine the action to be done. The contents are checked against the
match strings given in the DriveLoaderModule.INI-file. If there is no such a file, DriveLoader
module behaves as if one with empty content exists.

Beginning with DriveLoader module version 2.22, which is included in DriveWindow 2 version
2.22, it is possible to specify in DriveLoaderModule.INI the DDCS communication speed to be
used during system software backup and restore.

ABB Drives

DRIVELOADER MODULE

Technical Description

3AFE

00556549.DOC

Dept.

Project

AC DRIVES

Status Date

10.Sep 2008

Author

ERJANTI JYRKI

Status

APPROVED/ERJANTI JYRKI

Revision

Page

3 / 8

3. Matching

The characters in match strings given in the DriveLoaderModule.INI-file are used in matching as
follows.

Character Matches

Any single character

Zero or more (any) characters

Carriage return (13)

Line feed (10)

Form feed (12)

Horizontal tab (9)

0x01, 0x02, 0x7F, 0xFF

Skipped (cannot be used in matching)

0x00

Must not be used

Any other

Matches the character itself and, if matching is case
insensitive, the corresponding lower or upper case character
as well.

Note that matching is always done against the total content of a SW_PACK*.TXT file. So, a
match string typically begins and ends with an asterisk.

4. INI-file Content

There are three reserved section names in the INI-file:

•

[CommSpeed]

•

[RestoreDefaults]

•

[CurrentSW]

The first section (

[CommSpeed]

) is new in DriveLoaderModule version 2.22.

4.1. CommSpeed Section

The section defines minimum and maximum communication speeds in megabauds to be used
during system software backup and restore. Definitions are separate for NDPA-02 (or NISA-03)
and RUSB-02.

Note that although using high communication speed shortens the system software backup and
restore time, there is a risk of failure, which requires restarting the drive to recover the original
communication speed. So, do not use this feature unless you consider yourself a specialist.

Note also that RUSB-02 communication may actually slow down considerably with higher baud
rates. The reason is that on many platforms the Microsoft HID driver used in RUSB-02
communication begins to lose USB interrupts and falls back to polling.

If the current communication speed is between the specified minimum and maximum values,
communication speed is not changed during system software backup and restore.

ABB Drives

DRIVELOADER MODULE

Technical Description

3AFE

00556549.DOC

Dept.

Project

AC DRIVES

Status Date

10.Sep 2008

Author

ERJANTI JYRKI

Status

APPROVED/ERJANTI JYRKI

Revision

Page

4 / 8

The following keys can be included in the

[CommSpeed]

section.

Key Type

Default

Description

MinBauds

integer

The minimum baudrate for system software
backup and restore for NDPA-02 (and NISA-
03).

MaxBauds

integer

The maximum baudrate for system software
backup and restore for NDPA-02 (and NISA-
03).

RUSBMinBauds

integer

The minimum baudrate for system software
backup and restore for RUSB-02.

RUSBMaxBauds

integer

The maximum baudrate for system software
backup and restore for RUSB-02.

The following are examples of backup and restore times of ASXR7320. Note that 8 MBaud
speed could not be used because it did not work reliably enough. Note also the serious slow
down in RUSB-02 with 4 MBaud speed. Time is in minutes-colon-seconds.

Device

Function

1 MBaud

2 MBauds

4 MBauds

8 MBauds

NDPA-02

Backup 3:12 2:16 2:16 n/a

NDPA-02

Restore 8:21 7:13 7:08 n/a

RUSB-02

Backup 8:28 7:24

29:55 n/a

RUSB-02

Restore 14:29 13:25 42:58 n/a

4.2. RestoreDefaults Section

The section defines some default values that take effect if not overridden by a match.

The following keys can be included in the

[RestoreDefaults]

section.

Key Type

Default

Description

LoadFluxToRAM

integer

0: The new drive operating system is loaded
to RAM only if absolutely necessary.
1: The new drive operating system is always
loaded to RAM.
Else: Restoring is denied.

MatchIsCaseSensitive

integer

If nonzero, case of the letters is meaningful
during matching.

4.3. CurrentSW Section

The section is used to determine the software currently in the Flash memory of the drive.
Determination is done by trying to match content of the SW_PACK*.TXT file in the Flash memory
against the

MatchCurrentSW

values listed in the section.

If no match is found, the default

LoadFluxToRAM

action is valid.

ABB Drives

DRIVELOADER MODULE

Technical Description

3AFE

00556549.DOC

Dept.

Project

AC DRIVES

Status Date

10.Sep 2008

Author

ERJANTI JYRKI

Status

APPROVED/ERJANTI JYRKI

Revision

Page

5 / 8

The following keys can be included in the

[CurrentSW]

section.

Key Type

Description

MatchCurrentSW0

string

A match (wildcard) string.

NewSW0

string

Name of the section for determining the software in
the backup package.

LoadFluxToRAM0

integer

Empty or not given: the

LoadFluxToRAM

value given

in the

[RestoreDefaults]

section is used.

0: The new drive operating system is loaded to RAM
only if absolutely necessary.
1: The new drive operating system is always loaded
to RAM.
Else: Restoring is denied.
This can be overridden in the

NewSW0

section.

MatchIsCaseSensitive0

integer

Empty or not given: the

MatchIsCaseSensitive

value given in the

[RestoreDefaults]

section is

used.
0: case of the letters is not meaningful during this
match.
Nonzero: case of the letters is meaningful during this
match.

MatchCurrentSW

string

A match (wildcard) string.

NewSW

string

Name of the section for determining the software in
the backup package.

LoadFluxToRAM

integer

Empty or not given: the

LoadFluxToRAM

value given

in the

[RestoreDefaults]

section is used.

0: The new drive operating system is loaded to RAM
only if absolutely necessary.
1: The new drive operating system is always loaded
to RAM.
Else: Restoring is denied.
This can be overridden in the

NewSW0

section.

MatchIsCaseSensitive

integer

Empty or not given: the

MatchIsCaseSensitive

value given in the

[RestoreDefaults]

section is

used.
0: case of the letters is not meaningful during this
match.
Nonzero: case of the letters is meaningful during this
match.

Matching is done in order 0…n and terminates when the first match is found or the list is
exhausted. Note that the numbering must be consecutive without any missing numbers.

ABB Drives

DRIVELOADER MODULE

Technical Description

3AFE

00556549.DOC

Dept.

Project

AC DRIVES

Status Date

10.Sep 2008

Author

ERJANTI JYRKI

Status

APPROVED/ERJANTI JYRKI

Revision

Page

6 / 8

If a match is found at i and there is a non-empty

NewSW

, the content of the SW_PACK*.TXT file

in the backup package is matched against

MatchNewSW

values listed in the section defined by

NewSW

Note that

LoadFluxToRAM

can be overridden in the

NewSW

section in case a match is found

there.

4.4. NewSW

Sections

The names of these sections are defined by

NewSW

values in the

[CurrentSW]

section.

This kind of section is used to determine the software in the backup package. Determination is
done by trying to match content of the SW_PACK*.TXT file in the package against the

MatchNewSW

values listed in the section.

If no match is found, the

LoadFluxToRAM

action defined by the match in the

[CurrentSW]

section is valid.

The following keys can be included in a

[<NewSW

section.

Key Type

Description

MatchNewSW0

string

A match (wildcard) string.

LoadFluxToRAM0

integer

Empty or not given: the

LoadFluxToRAM

value defined by the match in the

[CurrentSW]

section is used.

0: The new drive operating system is
loaded to RAM only if absolutely
necessary.
1: The new drive operating system is
always loaded to RAM.
Else: Restoring is denied.

MatchIsCaseSensitive0

integer

Empty or not given: the

MatchIsCaseSensitive

value given in

the

[RestoreDefaults]

section is

used.
0: case of the letters is not meaningful
during this match.
Nonzero: case of the letters is meaningful
during this match.

ABB Drives

DRIVELOADER MODULE

Technical Description

3AFE

00556549.DOC

Dept.

Project

AC DRIVES

Status Date

10.Sep 2008

Author

ERJANTI JYRKI

Status

APPROVED/ERJANTI JYRKI

Revision

Page

7 / 8

Key Type

Description

MatchNewSW

string

A match (wildcard) string.

LoadFluxToRAM

integer

Empty or not given: the

LoadFluxToRAM

value defined by the match in the

[CurrentSW]

section is used.

0: The new drive operating system is
loaded to RAM only if absolutely
necessary.
1: The new drive operating system is
always loaded to RAM.
Else: Restoring is denied.

MatchIsCaseSensitive

integer

Empty or not given: the

MatchIsCaseSensitive

value given in

the

[RestoreDefaults]

section is

used.
0: case of the letters is not meaningful
during this match.
Nonzero: case of the letters is meaningful
during this match.

Matching is done in order 0…m and terminates when the first match is found or the list is
exhausted. Note that the numbering must be consecutive without any missing numbers.

5. INI-file Example

Note that this example is made for demonstration purposes only.

Communication speed for NDPA-02 is at least 4 MBauds during system software backup and
restore. Other speeds have their default values, which are shown as comments (lines start with
semicolon). So, RUSB-02 speeds are never changed.

The following DriveLoaderModule.INI loads the new drive operating system to RAM before
restoring system software in case the current system software is meant for an RMIO board, its
version is not ASXR7270, ASXR7280, or ASXR729?, and the system software version in the
backup package is ASXR7270, ASXR7280, or ASXR729?.

If the current system software is meant for an RMIO board, but the system software in the
backup package is not, restoring is denied.

[CommSpeed]

MinBauds=4

;MinBauds=1

;MaxBauds=8

;RUSBMinBauds=1

;RUSBMaxBauds=8

[RestoreDefaults]

; The following is unnecessary because zero is the default

LoadFluxToRAM=0

; The following is unnecessary because zero is the default

MatchIsCaseSensitive=0

[CurrentSW]

MatchCurrentSW0=* RMIO * ASXR729? *

ABB Drives

DRIVELOADER MODULE

Technical Description

3AFE

00556549.DOC

Dept.

Project

AC DRIVES

Status Date

10.Sep 2008

Author

ERJANTI JYRKI

Status

APPROVED/ERJANTI JYRKI

Revision

Page

8 / 8

NewSW0=ASXR7270-729x

MatchCurrentSW1=* RMIO * ASXR7280 *

NewSW1=ASXR7270-729x

MatchCurrentSW2=* RMIO * ASXR7270 *

NewSW2=ASXR7270-729x

MatchCurrentSW3=* RMIO *

NewSW3=RMIO

LoadFluxToRAM3=2

[ASXR7270-729x]

MatchNewSW0=* RMIO *

LoadFluxToRAM0=0

MatchNewSW1=*

LoadFluxToRAM1=2

[RMIO]

MatchNewSW0=* RMIO * ASXR729? *

LoadFluxToRAM0=1

MatchNewSW1=* RMIO * ASXR7280 *

LoadFluxToRAM1=1

MatchNewSW2=* RMIO * ASXR7270 *

LoadFluxToRAM2=1

MatchNewSW3=* RMIO *

LoadFluxToRAM3=0

Document Outline

Technical Description of DriveLoaderModule.INI

Wyszukiwarka

Podobne podstrony:
description of a place (cambridge) HMA5SKKAUL7D3RYKCJF4LP4WF7Q5H5E56Q2JJIY
Criteria for the description of sounds
Description of the Resident and Situation
Description of business
description of a restaurant opis restauracji
description of animals word
The quantum description of optical phase
TECHNICAL ASPECTS OF REFLOATING OPERATIONS FOR(1)
BJJ Technique Descriptions
David Icke A Concise Description of the Illuminati
MSB09 Description of simple connection resistance calculator 2010 08 05
Description of history
A Lucid Description of the Stone
Criteria for the description of sounds
Description of Rosarium illustrations
description of monsters
Steve Smith Drumset Technique & History of the US beat
9 2 Qualitative Description of

więcej podobnych podstron

Technical Description of DriveLoaderModule INI

Document Outline
