89 TransAlp Manual Fuel System 4 8
f
FUELSYSTEM
INSTALLATION
Install the air cleaner case in the reverse order of removal. NOTĘ
(2) AIR DUCT BAND (SEE NOTEI
(3> AIR CLEANER CASE
(1) AIR DUCT
Awarning
CARBURETOR REM0VAL
<4| ELEMENT
• Keep gasotine away from /James or sparks. Wipe up spilled gasotine at once.
(51 INSULATOR
• Correct routing, see page 1-9.
• When installing the air duet band, apply oil to the inside of the tubę band.
Remove the fuel tank (page 4-3I.
Remove the air duet (page 4-7I.
Loosen the drain screws and drain the fuel into a Container.
Disconnect the throttle cables.
Disconnect the right and left side choke cables.
Loosen the insulator band screws.
Puli the carburetors upward and away from the engine.
11) INSULATOR
CARBURETOR DISASSEMBLY
NOTĘ
• The disassembly of the carburetor can be done without separating the carburetors.
Remove the insulator from the carburetor, loosening the screw.
Remove the fuel tubę.
4-8
