Warp Speed, Mr.

magine your desktop computer running at the

speed of light. Sure, the electrons that are

switches sitting on a bed of silicon really slow the works down. Rev those up
to the speed of light as well, and you’ll have a real screamer on your hands.

Fantasy? Not necessarily, and you’ll have your chance to help make it

a reality.

We first ran an article on the photonic transistor about a

half ago that described this new little wonder and some of its potential. Now

we go the next step in our first article this month and look at its potential for

use in full-blown computers. Many problems remain to be worked out, so
Intel doesn’t have to worry about the Pentium quite yet, but

when these little

holograms

become real, they could change the face of computing. Find out

what work is being done and how you can get involved.

I’m particularly fond of our second article because I was there when the

germ of the idea was planted. I first saw the original

at the

Exploritorium while I was visiting Shaun with some other college buddies

about seven years ago. Since then, we’ve both built

(though

mine pales in comparison) and I’ve had feedback from other Circuit Cellar
readers about their own experiences with the concept after they saw the
Wavy Sign, one of our Honorable Mentions in the Fifth Annual Circuit Cellar
Design Contest (by the way, this article was already in the works when that
contest entry came in, so it was a complete coincidence). Take a look and
have some fun.

Do you automatically fill in the interrupt vector table when you sit down

to develop a new embedded project? Are interrupts a way of life, no matter
what you’re trying to do? If so, you may want to rethink your philosophy.

Depending on what you’re trying to do, living without them can make your
life much easier, as our third article tries to show.

Next, the great debate over whether to use assembly language or a

high-level language continues, but what about a compromise? Our last
feature article describes a programming technique that combines the best of
both into a discipline that many would do well to adopt.

In our columns, Ed continues talking about how to add a large LCD

panel to his Firmware Development system with a discussion of the
hardware. Jeff adds some smarts to the new

thermostat chip to

make a networkable, intelligent thermostat. Tom crosses enemy lines into

the analog camp to look at some new chips that are bound to give the
venerable op-amp a run for its money. John introduces a new series in
which he’ll be describing how to build a general-purpose embedded control
system based on a compact backplane. Finally, Russ looks at patents that
deal with our theme of Applications in Light.
