HYUNDAI TIBURON 1997 2003

background image

Copyright 2002-2004 Triple S Customs

HYUNDAI TIBURON 1997-2003

V

V

E

E

H

H

I

I

C

C

L

L

E

E

W

W

I

I

R

R

I

I

N

N

G

G










background image

Copyright 2002-2004 Triple S Customs

2

WIRING INFORMATION 1997 Hyundai Tiburon

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

BLUE/BLACK

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

12V ACCESSORY WIRE

BLUE/YELLOW

Ignition harness

SECOND ACCESSORY WIRE

BLUE

Ignition harness

STARTER WIRE

BLACK/YELLOW

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Harness In Driver’s Kick Panel

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/BLUE

At Any Pin Switch

TRUNK TRIGGER (-)

BROWN/RED

At Trunk Light

TACHOMETER WIRE

BROWN/RED or BLUE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

BLUE/WHITE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLACK/YELLOW

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

At Passenger Door Window Switch

RIGHT FRONT WINDOW DOWN

BLACK/YELLOW

At Passenger Door Window Switch


WIRING INFORMATION 1998 Hyundai Tiburon

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

BLUE/BLACK

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

12V ACCESSORY WIRE

BLUE/YELLOW

Ignition harness

SECOND ACCESSORY WIRE

BLUE

Ignition harness

STARTER WIRE

BLACK/YELLOW

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Harness In Driver’s Kick Panel

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/BLUE

At Any Pin Switch

TRUNK TRIGGER (-)

BROWN/RED

At Trunk Light

TACHOMETER WIRE

BROWN/RED or BLUE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

BLUE/WHITE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLACK/YELLOW

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

At Passenger Door Window Switch

RIGHT FRONT WINDOW DOWN

BLACK/YELLOW

At Passenger Door Window Switch


WIRING INFORMATION 1999 Hyundai Tiburon

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

BLUE/RED

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

12V ACCESSORY WIRE

LT.BLUE/BLUE

Ignition harness

SECOND ACCESSORY WIRE

BLUE/BLACK

Ignition harness

STARTER WIRE

BLACK/WHITE

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Harness In Driver’s Kick Panel

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/BLUE

At Any Pin Switch

TRUNK TRIGGER (-)

BROWN

At Trunk Light

TACHOMETER WIRE

YELLOW or BROWN

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

GREEN/RED

Harness At Steering Column

LEFT FRONT WINDOW UP

BLUE/WHITE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BLACK/YELLOW

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE/WHITE

At Passenger Door Window Switch

RIGHT FRONT WINDOW DOWN

BLACK/YELLOW

At Passenger Door Window Switch

background image

Copyright 2002-2004 Triple S Customs

3

WIRING INFORMATION 2000 Hyundai Tiburon

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

WHITE/YELLOW

Ignition harness

12V IGNITION WIRE

BLACK/WHITE

Ignition harness

SECOND IGNITION WIRE

BLUE

Ignition harness

12V ACCESSORY WIRE

BLUE/BLACK

Ignition harness

STARTER WIRE

BLACK/WHITE

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Black Connector Above Fuse Box

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

BLACK/WHITE White

Connector

In Driver’s Kick Panel

TRUNK TRIGGER (-)

BLUE/WHITE

White Connector In Driver’s Kick Panel

TACHOMETER WIRE

BROWN/RED or LT.BLUE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

BLACK/WHITE

Harness At Steering Column

LEFT FRONT WINDOW UP

BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BROWN/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE

At Passenger Door Window Switch

RIGHT FRONT WINDOW DOWN

BROWN/BLACK

At Passenger Door Window Switch


WIRING INFORMATION 2001 Hyundai Tiburon

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

YELLOW/BLACK to BLUE

Ignition harness

12V IGNITION WIRE

BLACK/WHITE to BROWN

Ignition harness

ACCESSORY WIRE

RED/WHITE to GREEN/WHITE

Ignition harness

SECOND ACCESSORY WIRE

WHITE/BLUE to PINK

Ignition harness

STARTER WIRE

YELLOW/RED to GRAY

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Gray Connector Under Driver’s Side Dash

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

GREEN/WHITE

White Connector In Driver’s Kick Panel

TRUNK TRIGGER (-)

BLUE/WHITE

White Connector In Driver’s Kick Panel

TACHOMETER WIRE

BROWN/RED or LT.BLUE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

PINK/WHITE

Harness At Steering Column

LEFT FRONT WINDOW UP

BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BROWN/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE

At Passenger Door Window Switch

RIGHT FRONT WINDOW DOWN

BROWN/BLACK

At Passenger Door Window Switch


WIRING INFORMATION 2002 Hyundai Tiburon

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

YELLOW/BLACK to BLUE

Ignition harness

12V IGNITION WIRE

BLACK/WHITE to BROWN

Ignition harness

ACCESSORY WIRE

RED/WHITE to GREEN/WHITE

Ignition harness

SECOND ACCESSORY WIRE

WHITE/BLUE to PINK

Ignition harness

STARTER WIRE

YELLOW/RED to GRAY

Ignition harness

PARKING LIGHTS (+)

GREEN/WHITE

Gray Connector Under Driver’s Side Dash

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

GREEN/WHITE

White Connector In Driver’s Kick Panel

TRUNK TRIGGER (-)

BLUE/WHITE

White Connector In Driver’s Kick Panel

TACHOMETER WIRE

BROWN/RED or LT.BLUE/YELLOW

At Ignition Coil

BRAKE WIRE (+)

GREEN

Harness At Brake Pedal Switch

HORN TRIGGER (-)

PINK/WHITE

Harness At Steering Column

LEFT FRONT WINDOW UP

BLUE

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

BROWN/BLACK

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

BLUE

At Passenger Door Window Switch

RIGHT FRONT WINDOW DOWN

BROWN/BLACK

At Passenger Door Window Switch

background image

Copyright 2002-2004 Triple S Customs

4

WIRING INFORMATION 2003 Hyundai Tiburon

WIRE

WIRE COLOR

LOCATION

12V CONSTANT WIRE

RED

Ignition harness

12V IGNITION WIRE

RED

Ignition harness

12V ACCESSORY WIRE

PINK

Ignition harness

SECOND ACCESSORY WIRE

ORANGE

Ignition harness

STARTER WIRE

WHITE

Ignition harness

POWER DOOR LOCK (Interrupt wire with a
relay to lock doors)

YELLOW or BLUE

At BCM Attached To Fuse Box Under Dash

POWER DOOR UNLOCK (Negative trigger)

Same wire as lock

Power door lock wires only exist on models equipped with factory keyless entry. The same wire is used to lock and unlock the doors. A
negative pulse will unlock the doors and interrupting this wire with a relay will lock the doors. Use the driver’s door lock knob to test the
BLACK/ORANGE wire. Use the passenger door lock knob to test the BLUE wire.

PARKING LIGHTS (+)

PINK/BLACK and GREEN/ORANGE

At BCM Attached To Fuse Box Under Dash

DOOR TRIGGER/ DOMELIGHT
SUPERVISION (-)

YELLOW

At BCM Attached To Fuse Box Under Dash

TRUNK TRIGGER (-)

GREEN/BLACK

At BCM Attached To Fuse Box Under Dash

HOOD TRIGGER (-)

GREEN/ORANGE

At Factory Hood Pin

TRUNK RELEASE (+)

BLUE

Harness In Driver’s Kick Panel

TACHOMETER WIRE

WHITE

Connector In Passenger Kick Panel

BRAKE WIRE (+)

WHITE

Harness At Brake Pedal Switch

HORN TRIGGER (-)

GREEN/BLACK

Harness At Steering Column

LEFT FRONT WINDOW UP

BROWN

At Driver Window Motor Inside Door

LEFT FRONT WINDOW DOWN

ORANGE

At Driver Window Motor Inside Door

RIGHT FRONT WINDOW UP

YELLOW

Harness In Driver’s Kick From Driver Door

RIGHT FRONT WINDOW DOWN

PINK

Harness In Driver’s Kick From Driver Door

This vehicle is equipped with a factory Immobilizer system. This must be bypassed when installing a remote start system.
