Part Number: X08-75366

Course Number: 2373B

Released: 02/2002

Programming with Microsoft® Visual Basic® .NET

Manual Classroom Setup Guide

Information in this document, including URL and other Internet Web site references, is subject to change without notice. Unless otherwise noted, the example companies, organizations, products, domain names, e-mail addresses, logos, people, places and events depicted herein are fictitious, and no association with any real company, organization, product, domain name, e-mail address, logo, person, place or event is intended or should be inferred. Complying with all applicable copyright laws is the responsibility of the user. Without limiting the rights under copyright, no part of this document may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the express written permission of Microsoft Corporation.

Microsoft may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document. Except as expressly provided in any written license agreement from Microsoft, the furnishing of this document does not give you any license to these patents, trademarks, copyrights, or other intellectual property.

© 2002 Microsoft Corporation. All rights reserved.

Microsoft, MS-DOS, Windows, Windows NT, ActiveX, MSDN, PowerPoint, Visual Basic, and Visual Studio are either registered trademarks or trademarks of Microsoft Corporation in the U.S.A. and/or other countries.

The names of actual companies and products mentioned herein may be the trademarks of their respective owners.

Course Number: 2373B
Part Number: X08-75366
Released: 02/2002

Contents

Classroom Requirements 1

Classroom Configuration 3

Manual Classroom Setup 4

Instructor Computer Setup 5

Student Computer Setup 13

Classroom Requirements

This course requires a classroom with a minimum of one computer for the instructor and one for each student. Before class begins, install and configure all computers by using the following information and instructions. All hardware must be on the Hardware Compatibility List (HCL) for Microsoft®
Windows® XP Professional.

Instructor Computer

The instructor computer requires the following hardware and software configuration.

Hardware Level 3

The following hardware is the minimum required for the instructor computer:

• Pentium III 450

• PCI 2.1 bus

• 512 megabytes (MB) of RAM

• 12-gigabyte (GB) hard disk

• 512-kilobyte (KB) L2 cache

• DVD player

• Non-ISA network adapter (10/100 megabits per second (Mbps) required)

• 4-MB video adapter

• Super VGA (SVGA) monitor (17 inch)

• Microsoft Mouse or compatible pointing device

• Sound card with amplified speakers

• Internet access

• Projection display device that supports SVGA 800x600, 256-colors

Software

Please note that unless otherwise indicated, this software is not included on the Trainer Materials compact disc. This course was developed and tested on the following software, which is required for the instructor computer:

• Microsoft Windows XP Professional

• Microsoft SQL Server™ 2000 Developer Edition

• Microsoft Visual Basic® 6.0 Professional Edition

• Microsoft Visual Studio® .NET - Enterprise Architect Edition

• Microsoft Windows Component Update

• Microsoft Visio® for Enterprise Architects

• Microsoft PowerPoint® Viewer (included on the Trainer Materials compact disc)

• Macromedia Flash Player version 5.0 (included on the Trainer Materials compact disc)

Microsoft only supports this course on this base installation.

Student Computer

Each student computer requires the following hardware and software configuration.

Hardware Level 3

The following hardware is required for each student computer:

• Pentium III 450

• PCI 2.1 bus

• 512 MB of RAM

• 12-GB hard disk

• 512-KB L2 cache

• DVD player

• Non-ISA network adapter (10/100 Mbps required)

• 4-MB video adapter

• SVGA monitor (17 inch)

• Microsoft Mouse or compatible pointing device

• Sound card with headphones or speakers

Software

Please note that unless otherwise indicated, this software is not included on the Trainer Materials compact disc. This course was developed and tested on the following software, which is required for each student computer:

• Windows XP Professional

• SQL Server 2000 Developer Edition

• Visual Studio .NET - Enterprise Architect Edition

• Microsoft Windows Component Update

• Microsoft Visio for Enterprise Architects

Classroom Configuration

The following configuration and naming conventions are suggestions:

• The instructor computer is named London and has an IP address of 192.168.x.200.

• The student computers are named according to the following table.

The following table shows suggested names and IP addresses of the student computers. The computers can be installed in any order or concurrently. In the IP addresses, x is the classroom number.

Computer name	IP address
Vancouver	192.168.x.1
Denver	192.168.x.2
Perth	192.168.x.3
Brisbane	192.168.x.4
Lisbon	192.168.x.5
Bonn	192.168.x.6
Lima	192.168.x.7
Santiago	192.168.x.8
Bangalore	192.168.x.9
Singapore	192.168.x.10
Casablanca	192.168.x.11
Tunis	192.168.x.12
Acapulco	192.168.x.13
Miami	192.168.x.14
Auckland	192.168.x.15
Suva	192.168.x.16
Stockholm	192.168.x.17
Moscow	192.168.x.18
Caracas	192.168.x.19
Montevideo	192.168.x.20
Manila	192.168.x.21
Tokyo	192.168.x.22
Khartoum	192.168.x.23
Nairobi	192.168.x.24

Manual Classroom Setup

Use the following instructions to set up the classroom manually. For more information about the hardware levels for both the instructor and student computers, refer to the Classroom Requirements section in this guide.

Before You Begin

Before you set up the classroom, you will need to do the following:

• Read through all setup procedures.

• Make sure that you have the Trainer Materials compact disc that is provided with the course materials.

Estimated time to set up the classroom: 10 hours

Instructor Computer Setup

Use the following instructions to set up the instructor computer.

• Set up the hardware

1. Set up the hardware according to the manufacturer's instructions. (Refer to the hardware requirements.)

2. Configure the hard disk as drive C with at least a 12-GB partition formatted as FAT32.

Install and Configure Windows XP Professional

• Install Windows XP Professional

Tip

To speed up this installation, run SMARTDrive (smartdrv.exe), a utility that ships with Microsoft MS-DOS® version 6.22 and later, prior to running the Windows XP Professional setup program.

1. Boot the computer by using an MS-DOS disk that loads either CD or network drivers.

2. Insert the disc containing Microsoft Windows XP Professional into the
   CD-ROM/DVD drive, or map a drive to the network share that contains the Windows XP Professional files.

3. Switch to the \i386 folder on the CD-ROM/DVD or network share.

4. Type winnt, and then press ENTER.

5. Setup will ask for the path where the Windows XP Professional files are located. Press ENTER to accept the default path displayed, or type the correct path for your computer and then press ENTER.

Windows XP Professional files will be copied to the hard disk.

1. Follow the prompts to install Windows XP Professional. Use the parameters provided in the following table. Respond to all other installation prompts with defaults or with information appropriate for your computer or location.

For this information	Use
Partition	Install to drive C: Convert to the NTFS file system.
Name and Organization	Provide your name and your organization.
Computer name	Use a computer name that is unique within your intranet (the suggested name is London, but use another name if London is already used on your intranet).
Administrator account password	Leave blank.
Networking settings	Choose Typical settings. - Or - If DHCP is not available on your network, choose Custom settings and then provide a unique static IP address (the suggested address is 192.168.x.200).
Workgroup or computer domain	Accept the default.

• Configure Windows XP Professional

1. Use the following table as a guide to configuring Windows XP Professional.

Decision point	Action
Welcome to Microsoft Windows	Click Next.
Will this computer connect to the Internet directly, or through a network?	Click Next.
Ready to activate Windows?	If you do not want to activate this copy of Windows XP at this time, then click No. Otherwise, click Yes, and then supply and submit registration information.
Who will use this computer?	Type Instructor.
Thank You	Click Finish.

2. Click start, and then click Control Panel.

3. Click User Accounts.

4. In the User Accounts dialog box, click Instructor, and then click Create a password.

5. In the Type a new password and Type the new password again to confirm boxes, type password and then click Create Password.

6. In the Do you want to make your files and folders private? dialog box, click No.

7. Close the User Accounts dialog box, and then close Control Panel.

• Add Internet Information Services (IIS)

1. Insert the Windows XP Professional installation disc into the
   CD-ROM/DVD drive, or map a drive letter to the network location that contains the Windows XP Professional installation \i386 folder.

2. Click start, and then click Control Panel.

3. Click Add or Remove Programs.

4. In the Add or Remove Programs dialog box, click Add/Remove Windows Components.

5. Place a check next to Internet Information Services (IIS), and then click Next.

6. If the Files Needed dialog box is displayed, browse to the location of the Windows XP Professional \i386 folder and then click OK.

Note

If the Windows XP Professional installation CD is in your
CD-ROM/DVD drive, you will not see the Files Needed dialog box.

1. Click Finish.

2. Close the Add or Remove Programs dialog box.

• Set the video display

1. In Control Panel, click Appearance and Themes, and then click Change the screen resolution.

2. Set the following options:

• Set the Color quality to at least Medium (16 bit).

• Set the Screen resolution to 1024 by 768 pixels.

Note

If possible, set the refresh frequency on the monitor to a value greater than 60 Hertz. Right-click the desktop, and then click Properties. Click Settings, and then click Advanced. Click Monitor, and then change the Screen refresh rate to any value greater than 60 Hertz from the list control on the Monitor tab.

Install SQL Server 2000 Developer Edition

• Install SQL Server 2000 Developer Edition

1. Insert the SQL Server 2000 Developer Edition compact disc into the CD-ROM/DVD drive.

2. On the SQL Server screen, click SQL Server 2000 Components.

3. On the Install Components screen, click Install Database Server.

4. Click Next in the following dialog boxes:

• Welcome

• Computer Name

• Installation Selection

1. In the User Information dialog box, type the appropriate information, and then click Next.

2. In the Software License Agreement dialog box, click Yes if you agree to the terms.

3. Click Next in the following dialog boxes:

• Installation Definition

• Instance Name

• Setup Type

1. In the Service Accounts dialog box, click Use the Local System account, and then click Next.

2. In the Authentication Mode dialog box, click Next.

3. In the Start Copying Files dialog box, click Next.

4. In the Setup Complete dialog box, click Finish.

Install Visual Basic 6.0 Professional Edition

• Install Visual Basic 6.0 Professional Edition

1. Insert the Microsoft Visual Basic 6.0 Professional Edition CD into the
   CD-ROM/DVD drive.

2. If required double-click setup.exe.

3. In the Installation Wizard for Visual Basic 6.0 Professional Edition dialog box, click Next.

4. If you accept the terms of the license agreement, click I accept the agreement, and then click Next.

5. Enter your product key, and then click Next.

6. Click Install Visual Basic 6.0 Professional Edition, and then click Next.

7. If required, change the folder location for common files, and then click Next.

8. In the Visual Basic 6.0 Professional Setup dialog box, click Continue, and then click OK.

9. When prompted for the type of installation, click Typical.

Visual Basic files will be copied to your computer.

10. When prompted, click Restart Windows.

11. Clear Install MSDN and click Next. Click Yes to continue without installing Microsoft MSDN®.

12. In the Server Setups dialog box, click Next.

13. In the Register Over the Web Now! dialog box, clear Register Now, and then click Finish.

Install and Configure Windows Component Update and
Visual Studio .NET

• Install Windows Component Update

1. Insert Visual Studio .NET CD1 into the CD-ROM/DVD drive.

2. In the Visual Studio .NET Setup dialog box, click Windows Component Update.

3. Enter the CD-ROM/DVD drive letter. Remove CD1 and insert the Windows Component Update disc into the CD-ROM/DVD drive. Click OK.

4. If you accept the terms of the license agreement, click I accept the agreement, and then click Continue.

5. Click Install Now.

6. Click Done after Windows Component Update has been installed.

• Install Microsoft Visual Studio .NET

1. In the Visual Studio .NET Setup dialog box, click Visual Studio .NET.

2. Enter the CD-ROM/DVD drive letter. Remove the Windows Component Update CD, insert Visual Studio .NET CD1, and then click OK.

3. If you accept the licensing agreement, click I accept the agreement. Enter your Product Key, and then click Continue.

4. On the Options Page, expand the Language Tools tree, and clear the Visual C++® .NET and Visual C#™ .NET check boxes.

5. Click Install Now.

6. When prompted, remove CD1, and then insert Visual Studio .NET CD2. Click OK.

7. When prompted, remove CD2, and then insert Visual Studio .NET CD3. Click OK.

8. When prompted, remove CD3, and then insert Visual Studio .NET CD4. Click OK.

9. In the Setup is complete dialog box, click Done.

10. In the Visual Studio .NET Setup dialog box, click Exit.

Install Visio for Enterprise Architects

• Install Visio for Enterprise Architects

1. Insert the Visio for Enterprise Architects CD-ROM into the CD-ROM/DVD drive.

2. In the Welcome to Microsoft Visio dialog box, click Next.

3. Accept the licensing agreement if you agree to the terms.

4. Click Customize.

5. In the Visio Installation Location dialog box, click Next. The default location is C:\Program Files\Microsoft Office.

6. In the Features list, click Visio. Click Run all from My Computer, and then click Install.

7. Click OK when Visio installation is complete.

Install Course Files

• Set the folder options to show operating system files and hidden files

1. Right-click start, and then click Explore.

2. On the Tools menu, click Folder Options, and then click View.

3. Click Display the contents of system folders.

4. Click Show hidden files and folders.

5. Clear the Hide extensions for known file types check box.

6. Clear the Hide protected operating system files check box.

7. In the Warning dialog box, click Yes.

8. Click OK.

• Install the course files: lab, practice and demonstration files

1. Insert the Trainer Materials compact disc into the CD-ROM/DVD drive and close the auto-run window.

2. Open the StudentCD\Webfiles\Downloads folder on the Trainer Materials compact disc.

3. Run Allfiles.exe, a self-extracting file.

4. Install all files to their default locations by clicking Unzip.

Note

By default, course files are installed to the following locations:

• Demonstration code files are installed in C:\Program Files\
  Msdntrain\2373\DemoCode.

• Labs are installed in C:\Program Files\Msdntrain\2373\Labs.

• Practices are installed in C:\Program Files\Msdntrain\2373\Practices.

• Do not change the default installation paths.

1. Click OK, and then click Close.

Install the PowerPoint Slides

• Install instructor PowerPoint slides

1. Open the Tools folder on the Trainer Materials compact disc.

2. Run 2373_ppt.msi.

Note

By default, instructor PowerPoint slides are installed to
C:\Program Files\Msdntrain\2373\Powerpnt.

Install the PowerPoint Viewer

• Install PowerPoint Viewer on the instructor computer

• Double-click viewer.vbs in the Pptview folder on the Trainer Materials CD-ROM.

Install Courseware Fonts

• Install fonts on the instructor computer

1. In the Tools folder on the Trainer Materials CD-ROM, double-click Fonts.exe.

2. In the Courseware fonts dialog box, click Yes.

3. In the Courseware fonts dialog box, click OK.

Install the Macromedia Flash 5.0 Plug-In

• Install the Macromedia Flash 5.0 plug-in

1. In the StudentCD\Flash folder on the Trainer Materials CD-ROM, double-click Flash5A.exe.

2. In the Flash 5 ActiveX® Control Installer dialog box, click Yes to install the control.

3. When installation is complete, click OK.

• Create the Internet Information Services (IIS) virtual directories

1. Click start, and then click Control Panel.

2. Click Performance and Maintenance, and then click Administrative Tools.

3. Double-click Internet Information Services.

4. Expand computername (where computername is the name of the computer).

5. Expand Web Sites.

6. Right-click Default Web Site, point to New, and then click
   Virtual Directory.

7. Complete the Virtual Directory Creation Wizard by using the information in the following table.

On this wizard page	Do this
Welcome to the Virtual Directory Creation Wizard	Click Next.
Virtual Directory Alias	In the Alias box, type 2373 and then click Next.
Web Site Content Directory	In the Directory box, type C:\Program Files\Msdntrain\2373 and then click Next.
Access Permissions	Click Next.
You have successfully completed the Virtual Directory Creation Wizard.	Click Finish.

8. Expand 2373, expand DemoCode, expand Mod07, and then expand LogonDemo.

9. Right-click Solution, and click Properties.

10. On the Directory tab, click Create to create an IIS application for this folder, and then click OK.

11. Repeat steps 8, 9 and 10 to configure the following folders:

• 2373/DemoCode/Mod07/Services/Solution

• 2373/DemoCode/Mod09/SimpleUserControl/Solution

• 2373/DemoCode/Mod10

• 2373/Labs/Lab071

• 2373/Labs/Lab071/Solution

• 2373/Labs/Lab072/Ex01/Starter

• 2373/Labs/Lab072/Ex01/Solution

• 2373/Labs/Lab072/Ex05/Starter

• 2373/Labs/Lab072/Ex05/Solution

• 2373/Labs/Lab081/Ex03/Solution

• 2373/Labs/Lab092/Ex01/Starter

• 2373/Labs/Lab092/Ex01/Solution

• 2373/Labs/Lab092/Ex02/Starter

• 2373/Labs/Lab092/Ex02/Solution

1. Close Internet Information Services.

• Create the Cargo database

1. On the start menu, point to All Programs, point to Microsoft SQL Server, and then click Query Analyzer.

2. In the Connect to SQL Server dialog box, enter the following information, and then click OK.

Setting	Value
SQL Server	localhost
Connect using	Windows authentication

3. On the File menu, click Open.

4. Locate the Setup folder on the Trainer Materials CD-ROM, click cargo.sql, and then click Open.

5. On the Query menu, click Execute, and wait for the script to run.

6. Close SQL Query Analyzer.

Student Computer Setup

Use the following instructions to set up all student computers.

• Set up the hardware

1. Set up the hardware according to the manufacturer's instructions. (Refer to the hardware requirements.)

2. Configure the hard disk as drive C with at least a 12-GB partition formatted as FAT32.

Install and Configure Windows XP Professional

• Install Windows XP Professional

Tip

To speed up this installation, run SMARTDrive (smartdrv.exe), a utility that ships with Microsoft MS-DOS version 6.22 and later, prior to running the Windows XP Professional setup program.

1. Boot the computer by using an MS-DOS disk that loads either CD or network drivers.

2. Insert the disc containing Microsoft Windows XP Professional into the
   CD-ROM/DVD drive, or map a drive to the network share that contains the Windows XP Professional files.

3. Switch to the \i386 folder on the CD-ROM/DVD or network share.

4. Type winnt, and then press ENTER.

5. Setup will ask for the path where the Windows XP Professional files are located. Press ENTER to accept the default path displayed, or type the correct path for your computer and then press ENTER.

Windows XP Professional files will be copied to the hard disk.

6. Follow the prompts to install Windows XP Professional. Use the parameters provided in the following table. Respond to all other installation prompts with defaults or with information appropriate for your computer or location.

For this information	Use
Partition	Install to drive C: Convert to the NTFS file system.
Name and Organization	Provide your name and your organization.
Computer name	Use a computer name that is unique within your intranet. See the Classroom Configuration section for naming suggestions.
Administrator account password	Leave blank.

(continued)

For this information	Use
Networking settings	Choose Typical settings. If DHCP is not available on your network, choose Custom settings and then provide a unique static IP address. See the IP addresses listed in the table in the Classroom Configuration section.
Workgroup or computer domain	Accept the default.

• Configure Windows XP Professional

1. Use the following table as a guide to configuring Windows XP Professional.

Decision point	Action
Welcome to Microsoft Windows	Click Next.
Will this computer connect to the Internet directly, or through a network?	Click Next.
Ready to activate Windows?	If you do not want to activate this copy of Windows XP at this time, then click No. Otherwise, click Yes, and then supply and submit registration information.
Who will use this computer?	Type values as appropriate. The values shown below are examples.
Your name:	Type Student1
2^nd User:	Type Student2
3^rd User:	Type Student3
4^th User:	Type Student4
5^th User:	Type Student5
Thank You	Click Finish.

2. Click start, and then click Control Panel.

3. Click User Accounts.

4. In the User Accounts dialog box, click Studentx (where x is the student number for the computer), and then click Create a password.

5. In the Type a new password and Type the new password again to confirm boxes, type password and then click Create Password.

6. In the Do you want to make your files and folders private? dialog box, click No.

7. Close the User Accounts dialog box, and then close Control Panel.

• Add Internet Information Services (IIS)

1. Insert the Windows XP Professional installation disc into the
   CD-ROM/DVD drive, or map a drive letter to the network location that contains the Windows XP Professional installation \i386 folder.

2. Click start, and then click Control Panel.

3. Click Add or Remove Programs.

4. In the Add or Remove Programs dialog box, click Add/Remove Windows Components.

5. Place a check next to the Internet Information Services (IIS), and then click Next.

6. If the Files Needed dialog box is displayed, browse to the location of the Windows XP Professional \i386 folder, and then click OK.

Note

If the Windows XP Professional installation CD is in your
CD-ROM/DVD drive, you will not see the Files Needed dialog box.

1. Click Finish.

2. Close the Add or Remove Programs dialog box.

• Set the video display

1. In Control Panel, click Appearance and Themes, and then click Change the screen resolution.

2. Set the following options:

• Set the Color quality to at least Medium (16 bit).

• Set the Screen resolution to 1024 by 768 pixels.

Note

If possible, set the refresh frequency on the monitor to a value greater than 60 Hertz. Right-click the desktop, and then click Properties. Click Settings, and then click Advanced. Click Monitor, and then change the Screen refresh rate to any value greater than 60 Hertz from the list control on the Monitor tab.

Install SQL Server 2000 Developer Edition

• Install SQL Server 2000 Developer Edition

1. Insert the SQL Server 2000 Developer Edition compact disc into the
   CD-ROM/DVD drive.

2. On the SQL Server screen, click SQL Server 2000 Components.

3. On the Install Components screen, click Install Database Server.

4. Click Next in the following dialog boxes:

• Welcome

• Computer Name

• Installation Selection

1. In the User Information dialog box, type the appropriate information, and the click Next.

2. In the Software License Agreement dialog box, click Yes if you agree to the terms.

3. Click Next in the following dialog boxes:

• Installation Definition

• Instance Name

• Setup Type

1. In the Services Accounts dialog box, click Use the Local System account, and then click Next.

2. In the Authentication Mode dialog box, click Next.

3. In the Start Copying Files dialog box, click Next.

4. In the Setup Complete dialog box, click Finish.

Install and Configure Windows Component Update and Visual Studio .NET

• Install Windows Component Update

1. Insert Visual Studio .NET CD1 into the CD-ROM/DVD drive.

2. In the Visual Studio .NET Setup dialog box, click Windows Component Update.

3. Enter the CD-ROM/DVD drive letter. Remove CD1 and insert the Windows Component Update disc into the CD-ROM/DVD drive. Click OK.

4. If you accept the terms of the license agreement, click I accept the agreement, and then click Continue.

5. Click Install Now.

6. Click Done after Windows Component Update has been installed.

• Install Microsoft Visual Studio .NET

1. In the Visual Studio .NET Setup dialog box, click Visual Studio .NET.

2. Enter the CD-ROM/DVD drive letter. Remove the Windows Component Update CD, insert Visual Studio .NET CD1, and then click OK.

3. If you accept the licensing agreement, click I accept the agreement, enter your Product Key, and then click Continue.

4. On the Options page, expand the Language Tools tree, and then clear the Visual C++ .NET and Visual C# .NET check boxes.

5. Click Install Now.

6. When prompted, remove CD1, and then insert Visual Studio .NET CD2. Click OK.

7. When prompted, remove CD2, and then insert Visual Studio .NET CD3. Click OK.

8. When prompted, remove CD3, and then insert Visual Studio .NET CD4. Click OK.

9. In the Setup is complete dialog box, click Done.

10. In the Visual Studio .NET Setup dialog box, click Exit.

Install Visio for Enterprise Architects

• Install Visio for Enterprise Architects

1. Insert the Visio for Enterprise Architects CD-ROM into the CD-ROM/DVD drive.

2. In the Welcome to Microsoft Visio dialog box, click Next.

3. Accept the licensing agreement if you agree to the terms.

4. Click Customize.

5. In the Visio Installation Location dialog box, click Next. The default location is C:\Program Files\Microsoft Office.

6. In the Features list, click Visio. Click Run all from My Computer, and then click Install.

7. Click OK when Visio installation is complete.

Install Course Files

• Set the folder options to show operating system files and hidden files

1. Right-click start, and then click Explore.

2. On the Tools menu, click Folder Options, and then click View.

3. Click Display the contents of system folders.

4. Click Show hidden files and folders.

5. Clear the Hide extensions for known file types check box.

6. Clear the Hide protected operating system files check box.

7. In the Warning dialog box, click Yes.

8. Click OK.

• Install the course files: lab, practice and demonstration files

1. Insert the Trainer Materials compact disc into the CD-ROM/DVD drive and close the auto-run window.

2. Open the StudentCD\Webfiles\Downloads folder on the Trainer Materials compact disc.

3. Run Allfiles.exe, a self-extracting file.

4. Install all files to their default locations by clicking Unzip.

Note

By default, course files are installed to the following locations:

• Demonstration code files are installed in C:\Program Files\
  Msdntrain\2373\DemoCode.

• Labs are installed in C:\Program Files\Msdntrain\2373\Labs.

• Practices are installed in C:\Program Files\Msdntrain\2373\Practices.

• Do not change the default installation paths.

1. Click OK, and then click Close.

• Create the Internet Information Services (IIS) virtual directories

1. Click start, and then click Control Panel.

2. Click Performance and Maintenance, and then click Administrative Tools.

3. Double-click Internet Information Services.

4. Expand computername (where computername is the name of the computer).

5. Expand Web Sites.

6. Right-click Default Web Site, point to New, and then click Virtual Directory.

7. Complete the Virtual Directory Creation Wizard by using the information in the following table.

On this wizard page	Do this
Welcome to the Virtual Directory Creation Wizard	Click Next.
Virtual Directory Alias	In the Alias box, type 2373 and then click Next.
Web Site Content Directory	In the Directory box, type C:\Program Files\Msdntrain\2373 and then click Next.
Access Permissions	Click Next.
You have successfully completed the Virtual Directory Creation Wizard.	Click Finish.

8. Expand 2373, expand DemoCode, expand Mod07, and then expand LogonDemo.

9. Right-click Solution, and click Properties.

10. On the Directory tab, click Create to create an IIS application for this folder, and then click OK.

11. Repeat steps 8, 9 and 10 to configure the following folders:

• 2373/DemoCode/Mod07/Services/Solution

• 2373/DemoCode/Mod09/SimpleUserControl/Solution

• 2373/DemoCode/Mod10

• 2373/Labs/Lab071

• 2373/Labs/Lab071/Solution

• 2373/Labs/Lab072/Ex01/Starter

• 2373/Labs/Lab072/Ex01/Solution

• 2373/Labs/Lab072/Ex05/Starter

• 2373/Labs/Lab072/Ex05/Solution

• 2373/Labs/Lab081/Ex03/Solution

• 2373/Labs/Lab092/Ex01/Starter

• 2373/Labs/Lab092/Ex01/Solution

• 2373/Labs/Lab092/Ex02/Starter

• 2373/Labs/Lab092/Ex02/Solution

1. Close Internet Information Services.

• Create the Cargo database

1. On the start menu, point to All Programs, point to Microsoft SQL Server, and then click Query Analyzer.

2. In the Connect to SQL Server dialog box, enter the following information, and then click OK.

Setting	Value
SQL Server	localhost
Connect using	Windows authentication

3. On the File menu, click Open.

4. Locate the Setup folder on the Trainer Materials CD-ROM, click cargo.sql, and then click Open.

5. On the Query menu, click Execute, and wait for the script to run.

6. Close SQL Query Analyzer.

ii Manual Classroom Setup Guide

Manual Classroom Setup Guide iii

20 Manual Classroom Setup Guide

Manual Classroom Setup Guide 19

L

L

---
