Overview

U=400V n
U=400V I
U=400V cos
U=400V η
U=400V Pel
U=400V Pmech
U=400V
U=300V n
U=300V cosφ
U=300V η
U=300V I
U=300V Pel
U=300V Pmech
U=300V

---

Sheet 1: U=400V n

---

Sheet 2: U=400V I

---

Sheet 3: U=400V cos

---

Sheet 4: U=400V η

---

Sheet 5: U=400V Pel

---

Sheet 6: U=400V Pmech

---

Sheet 7: U=400V

Lp	U [V]	P1 [W]	P2 [W]	I [A]	n [obr/min]	m [g]	T [Nm]	Pel [W]	cosφ	P mech	η [%]
1	400	-64	128	0,54	1495	0	0	64	0,171066746426556	0	0
2	400	-48	139	0,54	1484	257	0,180011538	91	0,243235530075259	27,9745340402608	30,7412461980888
3	400	-36	148	0,54	1473	503	0,352318302	112	0,299366806246473	54,3458729340619	48,5231008339839
4	400	-20	160	0,55	1464	761	0,533030274	140	0,367404716757035	81,7187228554405	58,3705163253146
5	400	-8	170	0,56	1453	1006	0,704636604	162	0,417547962538926	107,215958415739	66,182690380086
6	400	4	180	0,57	1442	1245	0,87204033	184	0,465931796188119	131,683223429001	71,5669692548919
7	400	20	192	0,58	1430	1500	1,050651	212	0,527578694259486	157,334199073803	74,2142448461334
8	400	36	208	0,61	1416	1764	1,235565576	244	0,577350269189626	183,21358436705	75,0875345766598
9	400	52	224	0,64	1404	2003	1,402969302	276	0,622455758970065	206,273716851159	74,7368539315795
10	400	64	238	0,66	1386	2224	1,557765216	302	0,660453717027526	226,096505647473	74,8663925985011
11	400	84	258	0,7	1368	2485	1,74057849	342	0,705192114510186	249,349400031427	72,9091812957389

---

Sheet 8: U=300V n

---

Sheet 9: U=300V cosφ

---

Sheet 10: U=300V η

---

Sheet 11: U=300V I

---

Sheet 12: U=300V Pel

---

Sheet 13: U=300V Pmech

---

Sheet 14: U=300V

Lp	U [V]	P1 [W]	P2 [W]	I [A]	n [obr/min]	m [g]	T [Nm]	Pel [W]	cosφ	P mech	η [%]
1	300	-26	62	0,32	1489	0	0	36	0,21650635094611	0	0
2	300	-12	72	0,33	1471	253	0,177209802	60	0,349909254054319	27,297886960328	45,4964782672134
3	300	2	86	0,35	1452	507	0,355120038	88	0,483874511320829	53,9970971221291	61,360337638783
4	300	16	100	0,38	1432	764	0,535131576	116	0,587479221280672	80,2476297567812	69,178991169639
5	300	30	114	0,42	1406	1046	0,732653964	144	0,659828879073858	107,873021238724	74,9118203046698
6	300	44	128	0,46	1383	1264	0,885348576	172	0,719595987685621	128,222751240701	74,548111186454
7	300	64	150	0,54	1349	1559	1,091976606	214	0,762672577818394	154,260204225792	72,0842075821456
8	300	78	170	0,6	1314	1771	1,240468614	248	0,795460370883484	170,690662312099	68,826879964556
9	300	88	184	0,66	1283	1910	1,33782894	272	0,793127642523122	179,744603662623	66,0825748759643
10	300	100	200	0,71	1256	2025	1,41837885	300	0,813169393224825	186,556551013664	62,1855170045548
