I [A] | 0.0 | 0.2 | 0.4 | 0.6 | 0.8 | 1.0 | 1.2 | 1.4 | 1.6 | 1.8 | 2.0 | 2.2 | 2.4 | 2.6 | |
B [T] | 0.02 | 0.08 | 0.14 | 0.21 | 0.27 | 0.34 | 0.40 | 0.46 | 0.53 | 0.59 | 0.65 | 0.71 | 0.78 | 0.84 | |
Uh [V], Ix [A]= | 0.02 | 0.00 | 0.15 | 0.25 | 0.35 | 0.50 | 0.58 | 0.69 | 0.78 | 0.85 | 0.95 | 1.03 | 1.11 | 1.20 | 1.26 |
Uh [V], Ix [A]= | 0.04 | 0.00 | 0.25 | 0.42 | 0.60 | 0.72 | 0.90 | 1.05 | 1.20 | 1.30 | 1.43 | 1.55 | 1.65 | 1.76 | 1.85 |
20mA | 0.03171533055254 | 0.126861322210159 | 0.222007313867779 | 0.333010970801668 | 0.428156962459288 | 0.539160619393177 | 0.634306611050797 | 0.729452602708416 | 0.840456259642306 | 0.935602251299926 | 1.03074824295755 | 1.12589423461516 | 1.23689789154905 | 1.33204388320667 | |
40mA | 0.047515570538826 | 0.190062282155305 | 0.332608993771784 | 0.498913490657677 | 0.641460202274156 | 0.807764699160048 | 0.950311410776527 | 1.09285812239301 | 1.2591626192789 | 1.40170933089538 | 1.54425604251186 | 1.68680275412834 | 1.85310725101423 | 1.99565396263071 | |
Współczynniki regresji: | |||||||||||||||
1.586 | dla Ix = 20mA | A/T | n= | 1.312E+20 | 1/m | n= | 1.312E+15 | 1/cm^-3 | |||||||
2.376 | dla Ix = 40mA | A/T | n= | 1.751E+20 | 1/m | n= | 1.751E+15 | 1/cm^-3 | |||||||
0.0006 | - d [m] | ||||||||||||||
1.602189E-19 | - ładunek elektronu [C] | ||||||||||||||
B = const | zasilacz [A] = | 0.6 | B1 [T] = | 0.21 | |||||||||||
Ix [mA] | 0 | 5 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | ||||
Ix [A] | 0.000 | 0.005 | 0.010 | 0.015 | 0.020 | 0.025 | 0.030 | 0.035 | 0.040 | 0.045 | 0.050 | ||||
Uh [V] | 0.00 | 0.10 | 0.20 | 0.30 | 0.38 | 0.45 | 0.51 | 0.60 | 0.65 | 0.70 | 0.72 | ||||
regresja | 0.00 | 0.08 | 0.16 | 0.24 | 0.32 | 0.40 | 0.49 | 0.57 | 0.65 | 0.73 | 0.81 | ||||
współczynnik regresji: | 16.1714285714286 | V/A | n= | 1.351E+20 | 1/m | n= | 1.351E+15 | 1/cm^-3 | |||||||
x*y | 0.0000 | 0.0005 | 0.0020 | 0.0045 | 0.0076 | 0.0113 | 0.0153 | 0.0210 | 0.0260 | 0.0315 | 0.0360 | 0.1557 | |||
x*x | 0.000000 | 0.000025 | 0.000100 | 0.000225 | 0.000400 | 0.000625 | 0.000900 | 0.001225 | 0.001600 | 0.002025 | 0.002500 | 0.009625 | |||
B = const | zasilacz [A] = | 1 | B1 [T] = | 0.34 | |||||||||||
Ix [A] | 0.000 | 0.005 | 0.010 | 0.015 | 0.020 | 0.025 | 0.030 | 0.035 | 0.040 | 0.045 | 0.050 | ||||
Uh [V] | 0.00 | 0.15 | 0.30 | 0.43 | 0.59 | 0.70 | 0.80 | 0.90 | 1.00 | 1.05 | 1.10 | ||||
regresja | 0.00 | 0.12 | 0.25 | 0.37 | 0.49 | 0.62 | 0.74 | 0.86 | 0.99 | 1.11 | 1.23 | ||||
współczynnik regresji: | 24.6493506493506 | V/A | n= | 1.435E+20 | n= | 1.435E+15 | 1/cm^-3 | ||||||||
B = const | zasilacz [A] = | 1.6 | B1 [T] = | 0.53 | |||||||||||
Ix [A] | 0.000 | 0.005 | 0.010 | 0.015 | 0.020 | 0.025 | 0.030 | 0.035 | 0.040 | 0.045 | 0.050 | ||||
Uh [V] | 0.00 | 0.22 | 0.47 | 0.68 | 0.89 | 1.05 | 1.20 | 1.30 | 1.45 | 1.50 | 1.60 | ||||
regresja | 0.00 | 0.18 | 0.36 | 0.54 | 0.72 | 0.90 | 1.08 | 1.26 | 1.44 | 1.62 | 1.80 | ||||
współczynnik regresji: | 36.0571428571429 | V/A | n= | 1.529E+20 | n= | 1.529E+15 | 1/cm^-3 | ||||||||
